- Page 1 ISTRuzIoNI PeR l’uSo - INSTRucTIoNS foR uSe INSTRucTIoNS PouR l’uSageR - INSTRuccIoNeS PaRa el uSo gebRauchSaNleITuNg - gIdS vooR de gebRuIkeR...
-
Page 2: Table Of Contents
2006/95/EC Low Voltage directive. • 2004/108/EC Electromagnetic Compatibility directive. Additional information: This product underwent a test in a typical uniform configuration (all products manufactured by GENIUS S.p.A.). Grassobbio, October 22, 2009 Managing Director D. Gianantoni Notes on reading the instruction Read this installation manual to the full before you begin installing the product. -
Page 3: General Characteristics
1. GENERAL CHARACTERISTICS Thank you for choosing our product. GENIUS is sure that it will give you all the performances you are looking for. All our products are the result of a long experience in the field of the automated systems, reinforced by the fact of being part of the world leading group of this sector. -
Page 4: Board Layout
Pagina 1 SPRINT 11 SW Guide for the installer 4. BOARD LAYOUT Pos. Description Description Inputs terminal board OPEN B radio input memory storage push-button Outputs and battery terminal board RESET RESET push-button Power supply terminal board PROG Programming push-button... -
Page 5: Cn1 Terminal Board
SPRINT 11 SW Pagina 1 Guide for the installer 5.2. CN1 TERMINAL BOARD 5.2.1. O Terminals “OPB & COM”. Normally open contact. Connect any pulse generator (i.e. push- button, key selector, etc.) to these terminals which, closing the contact, must command a partial opening of the gate. -
Page 6: Cn4 Terminal Board
Pagina 1 SPRINT 11 SW Guide for the installer 5.4. CN4 TERMINAL BOARD 5.4.1. m AinS pOWer Supply Terminals “F, PE & N”. Connect the power cable of the 115/230Vac mains line to these terminals. The earthing cable must be connected to the central terminal, “PE”. -
Page 7: Operational Parameters
SPRINT 11 SW Pagina 1 Guide for the installer 7. OPERATIONAL PARAMETERS All programmable functions of the board depend on the DIP-SWITCHES “DP”. The following table shows the different options. Dip-switch Description Deceleration speed: use this dip-switch to adjust the motor speed during the deceleration phase. -
Page 8: Adjustment Of Motor Power
Pagina 1 SPRINT 11 SW Guide for the installer Gate at closure If the encoder operates during the gate closing movement, the consequence is a brief reversal of movement, then the control unit goes into STOP condition, disabling thus any automatic functions to make the obstacle removal possible. To resume normal memory-stored cycle, send an OPEN impulse after having removed the obstacle. -
Page 9: Memory Storing The Radio Code
SPRINT 11 SW Pagina 1 Guide for the installer 11. MEMORY STORING THE RADIO CODE The control unit has an integrated 2-channel decoding system. This system makes it possible to memory store, via the receiver module, both the OPEN A command and the OPEN B command. -
Page 10: Deletion Of Radio Codes
Pagina 0 SPRINT 11 SW Guide for the installer activated channel. When 5 seconds have elapsed from memory-storage of the last radio control the control unit automatically exits the learning stage. To check if the radio control was correctly memory stored, wait for 5 seconds after sending the code. - Page 11 SPRINT 11 SW Pagina 1 Guide for the installer...
