SurgeX Defender Series User Manual page 18

iv. Voltage Limits: Displays the over-voltage and under-voltage shutdown thresholds currently in use,
v.
c. Tools Menu:
i. Cycle Power: Commands the Surge + Diagnostic to perform a Power Cycle.
ii. Clear Device Memory: Permanently erases the events and timestamps contained in the Surge +
iii.
d. Help Menu:
i. Help Topics: Launches the Surge + Diagnostic Help, which includes troubleshooting information for
ii. Manual: Launches the Surge + Diagnostic Manual that is installed with the software package.
iii.
© 2013 SurgeX / Electronic Systems Protection, Inc. / Technical Support 800.645.9721 / www.surgex.com /
and allows for the selection of alternate values. *When Under-Voltage Shutdown is Disabled, the
Surge + Diagnostic will not actively shut off connected equipment during an under-voltage event.
However, the Surge + Diagnostic power relays will drop out and disconnect equipment around 40V.
This is because there is not enough voltage available to keep the relays latched.
Email: Allows for the configuration of email settings. The software is pre-loaded with "courtesy
account" settings that may be used for testing purposes. The email feature is only available when
the Surge + Diagnostic is connected to a PC with an internet connection and the Surge + Diagnostic
software running. This feature may not work with certain Internet Service Providers that block
outgoing SMTP communications – check with your ISP for compatibility. Please contact your IT staff
for assistance when configuring custom email settings.
Diagnostic microcontroller memory. Clearing the device memory does not affect Voltage
Thresholds.
Enhanced Logging Mode: Puts the Surge + Diagnostic into Enhanced Logging Mode.
the Surge + Diagnostic product and software, FAQ, and general information about Power Quality.
About: Displays the software revision of the Diagnostic Software program, the firmware revision of
the microcontroller in the connected Surge + Diagnostic, the unique chip ID of the microcontroller in
the connected Surge + Diagnostic, and ESP's telephone number for technical support.
User Manual
17
