7. Operating
7.1.2 PM 12 actual/and setup value Comparison
Step Key Function
Switch over to the service mode
Note! The setup values are influenced. When the service key is pressed a warning signal is emitted (K2 - see 3.2.3).
SERV
1
Press the SERVice key
The indicator lamp of the first measuring point flashes.
Selection of the measuring point
Press the SELect key
SEL
The indicator lamp of the selected measuring point flashes.
2
Alternatively: select all measuring points
Press the SELect key (12x) until all the indicator lamps light up
Start the setup/actual value comparison
SERV
Press the SERVice ke
3
The set up/actual value comparison is started. When all the odd indicator lamps flash, the setup/actual value comparison is
finished. At the same time, the monitoring of the selected measuring point is suppressed
Alternatively: Reject new setup value
RES
Press the RESet key
The service routine is canceled, the newly determined setup value is not saved.
Save actual value as setup value
Press MEMory key and hold
Press SERVice key
The current flow rate is saved as the setup value.
Operating sequence actual/and setup value Comparison
