- Page 1 GL100M GPS Locator User Manual TRACGL100MUM001 Revision: 1.00 http://www.queclink.com sales@queclink.com...
- Page 2 TRACGL100MUM001 General Notes Queclink offers this information as a service to its customers, to support application and engineering efforts that use the products designed by Queclink. The information provided is based upon requirements specifically provided to Queclink by the customers. Queclink has not undertaken any independent search for additional relevant information, including any information that may be in the customer’s possession.
-
Page 3: Table Of Contents
GL100M User manual Contents Contents ............................2 0. Revision history ..........................3 1. Introduction...........................4 2. Product Overview .........................5 2.1. Appearance..........................5 2.2. Buttons/Mini USB Interface Description ................5 2.3. Two Triple-Color LEDs Description ...................6 3. Getting Started ..........................7 3.1. Parts List..........................7 3.2. Battery Charging .........................7 3.3. -
Page 4: Revision History
GL100M User manual 0. Revision history Revision Date Author Description of change 1.00 2011-09-16 Cid Xu Initial TRACGL100MUM001 - 3 -... -
Page 5: Introduction
GL100M User manual 1. Introduction GL100M is a powerful GPS locator which is designed for vehicle, pets and asserts tracking. With superior receiving sensitivity, fast TTFF and GSM frequencies 850/900/1800/1900. Its location can be real time or schedule tracked by backend server or specified terminals. Based on the... -
Page 6: Product Overview
2. Product Overview 2.1. Appearance 2.2. Buttons/Mini USB Interface Description Button /Mini USB Interface Description Power Key Turn on GL100M Turn off GL100M (If power key is enabled). Function Key Geo-Fence mode Long press the key to enable/disable Geo-Fence ID0... -
Page 7: Two Triple-Color Leds Description
2.3. Two Triple-Color LEDs Description There are two triple-color LEDs in GL100M. Each LED shows red, green and blue to indicate different state of GL100M. For better understanding, we call them Red LED 1, Green LED 1, Blue LED 1 and Red LED 2, Green LED 2, Blue LED 2. -
Page 8: Getting Started
Note: Before the first time using GL100M, please full charge the battery. 3.3. Install SIM Card Use a screw driver to twist off the two screws on the side of GL100M. Then remove the screws and SIM cover. Insert the SIM card into the SIM cover according to the direction shown. -
Page 9: Turn On/Turn Off
3.4. Turn on/Turn off Turn on: Press the Power key at least 3 seconds and release it to turn on GL100M. At the same time, Red LED 1 will light on for 2~3 seconds. Then Green LED 1 starts to blink quickly which means searching the GSM network. -
Page 10: Troubleshooting And Safety Info
The function of power key was Enable the function of power GL100M. disabled by AT+GTFKS. key by AT+GTFKS. Unable to power off GL100M if Disconnect charger, and try charger connected. again. GL100M is turned on after The function of full power up Disable the function of full insert a charging cable. -
Page 11: Safety Info
Please do not put the device on the overheating or too humid place, avoid exposure to direct sunlight. Too high temperature will damage the device or even cause the battery explosion. Please do not use GL100M on the airplane or near medical equipment. TRACGL100MUM001...
