Daikin ATKC09RV2S Service Manual page 13

Si041264EC
Step
3 Release the harnesses
from the 2 hooks.
4 Disconnect the
terminals from the
terminal board.
5 Unfasten the 4 hooks.
Release the upper part
of the control PCB and
then pull up to remove.
Removal Procedure
Procedure
Hook
Hook
Hook
(R18248)
(R14609)
Control
PCB
(R11943)
Swing Motor / PCBs
Points
11
