Superstructure continued
CD3339 and CD3340B: Six section valve bank chassis
mounted; operated via dash mounted, pilot pressure
hydraulic joysticks.
Return line filter with full flow by-pass protection and
service indicator.
89 L (23.5 gal) hydraulic reservoir with sight level
gauge and steel side plating to guard against side impact
damage.
Hoist specifications
CD3330F and CD3330FL: Worm drive with counter-
balance valving. Equal speed power up and down.
CD3339 and CD3340B: Piston motor drive with
spring applied/hydraulic released brake.
Drum diameter:
CD3330F and CD3330FL: 0,24 m (9.69 in)
CD3339 and CD3340B: 0,27 m (10.63 in)
Maximum single line pull:
CD3330F and CD3330FL: 4854 kg (10,700 lb)
CD3339 and CD3340B: 6350 kg (14,000 lb)
Maximum single line speed:
CD3330F and CD3330FL: 26,8 m/min (88 fpm)
CD3339 and CD3340B: 36,6 m/min (120 fpm)
Maximum permissible single line pull:
CD3330F and CD3330FLL: 3855 kg (8,500 lb)
(12,7mm [1/2 inch] Python Ultra XIPS)
CD3339 and CD3340B: 4536 kg (10,000 lb)
(14,0mm [9/16 inch] EEIPS)
Rope length :
CD3330F and CD3330FL:
(three-section boom): 29,6 m (97 ft)
(four-section boom): 39,6 m (130 ft)
CD3339 and CD3340B: 36,6 m (120 ft)
Carrier
Frame
High strength alloy steel constructed with integral
outrigger housings; front and rear lifting, towing,
and tie-down lugs. 42 ft carrydeck size with 6350 kg
2
(14,000 lb) carrying capacity (CD3330F, CD3330FL
and CD3339) and 7711 kg (17,000 lb) carrying
capacity (CD3340B). Deck coated with anti-skid
treatment.
Shuttlelift CD3300 Series
Specifications
Outriggers
CD3330F, CD3330FL and CD3339: Front and rear
oblique type beams at all four corners with integral
holding valves. Outrigger pads form an integral part
of the beam.
CD3340B: Hydraulic telescoping beam with oblique
type jack provides extended and down and retracted
and down lifting capacities. Integral holding valves on
both beam and jack.
Padsize CD3300 Series:
18 cm x 20 cm (7.4 in x 7.8 in)
Maximum outrigger pad load:
CD3300F/FL/CD3339: 122 psi
CD3340B: 387 psi
Outrigger controls
CD3330F, CD3330FL and CD3339: Lever controls
located on dash panel which operate the beams in
pairs from side to side.
CD3340B: Two switch operation mounted on dash
panel. One -three- position rocker switch to select all
beams/jacks, left beams/jacks only, or right beams/
jacks only. Separate -four- way toggle switch to
activate beams out/in and jacks down/up. Level bubble
indicator located inside operators compartment.
*Independent outrigger controls available as an option.
Standard engine (Tier III)
Cummins QSB 3.3 L turbo-charged diesel rated at
63,4 kW (85 bhp) at 2600 rpm. Supplied with 110 V
engine block heater and air intake grid heater.
*Optional engine
G.M. 3.0 L EFI dual fuel (gasoline / L.P.) rated at
59,6 kW (80 bhp) at 2600 rpm.
Operators control station
Frame mounted, open air style control station with
cab shell. Includes all crane functions, driving controls,
and overhead safety glass. Other standard equipment
include a durable weather resistant seat with seat belt,
hourmeter, sight level bubble, and fire extinguisher.
The dash panel includes engine oil pressure gauge,
engine water temperature gauge, fuel gauge,
transmission low oil and high temperature warning
lights, low battery warning light, and brake system
low pressure warning light. The LSI (load indicator)
receiver is mounted to the top of the dash and
provides warning for A2B and exceeded load capacity.
*Denotes optional equipment
