OPERATING YOUR RADIO
General Operation
Power On/Off
Press the left-front knob (#1) to turn the unit on. will
RETROSOUND
appear on the screen.
Press and hold the left-front knob (#1) to turn the unit off.
will appear on the screen to confirm that it has turned off.
GOODBYE
Volume
Turn the left-front knob (#1) to adjust the volume between 0-46.
Source Mode
Turn the left-rear knob (#2) clockwise to select from available
listening sources: , , , , .
RADIO AUX 1 AUX 2 USB BT-Audio
(The USB source modes will not appear unless a USB device is
plugged in).
The auxiliary and USB inputs are located at the back of the radio
body. The auxiliary inputs may be used to play music from any
portable device with a standard 3.5mm headphone output, such
as a MP3 player, iPod or iPhone , portable CD player or portable
® ®
satellite radio receiver. The USB inputs allow you to play music from
a flash drive. To use these inputs, the cables must be routed to an
accessible area during installation.
Radio Tuning
Turn the right-front knob (#4) to tune to the next or previous
AM/FM frequency.
NOTE: When the radio is tuned to a strong stereo FM station, the stereo indicator will
appear on the upper right corner of the LCD screen (two oval circles).
15
