ADVAncED PARAMETERS

#15: Advanced parameters

FIBARO Roller Shutter 3 allows to customize its operation to user's
needs. The settings are available in the FIBARO interface as simple
options that may be chosen by selecting the appropriate box.
In order to configure the module (using the home center controller):
1. Go to the device options by clicking the icon:
2. Select the „Advanced" tab.
INPUT/OUTPUT CONFIGURATION
20. Switch type
This parameter defines as what type the device should treat the
switch connected to the S1 and S2 terminals.
This parameter is not relevant in gate operating modes (parameter
151 set to 3 or 4). In this case switch always works as a momentary
and has to be connected to S1 terminal.
Available settings: 0 – momentary switches
Default setting:
24. Inputs orientation
This parameter allows reversing the operation of switches connected
to S1 and S2 without changing the wiring.
Available settings: 0 - default (S1 - 1st channel, S2 - 2nd channel)
Default setting:
25. Outputs orientation
This parameter allows reversing the operation of Q1 and Q2 without
changing the wiring (in case of invalid motor connection) to ensure
proper operation.
Available settings: 0 - default (Q1 - 1st channel, Q2 - 2nd channel)
Default setting:
1 – toggle switches
2 – single, momentary switch (the switch
should be connected to S1 terminal)
2
Parameter size:
1 - reversed (S1 - 2nd channel, S2 - 1st channel)
0 Parameter size:
1 - reversed (Q1 - 2nd channel, Q2 - 1st channel)
0
Parameter size:
1 [byte]
1 [byte]
1 [byte]
