ASSOcIATIOnS

#11: Associations

Association (linking devices) - direct control of other devices within
the Z-Wave system network e.g. Dimmer, Relay Switch, Roller Shutter
or scene (may be controlled only through a Z-Wave controller).
The device provides the association of 3 groups:
1st association group – "Lifeline" reports the device status and al-
lows for assigning single device only (main controller by default).
2nd association group – "Roller Shutter" is assigned to shutter po-
sition control – uP/DOWn (uses Switch Multilevel command class).
3rd association group – "Slats" is assigned to slats position control
– uP/DOWn (uses Switch Multilevel command class).
The device in 2nd and 3rd group allows to control 5 regular or mul-
tichannel devices per an association group, with the exception of
"lifeline" that is reserved solely for the controller and hence only 1
node can be assigned.
To add an association (using the home center controller):
1. Go to the device options by clicking the icon:
2. Select the „Advanced" tab.
3. click the "Setting Association" button.
4. Specify to which group and what devices are to be associated.
5. Save the changes.
6. Wait for the configuration process to end.
Assocation groups mapping:
Root
Association Group 2
Association Group 3
Association Group in
Endpoint
Endpoint 1 Association Group 2
Endpoint 2 Association Group 2
Endpoint
