Parts lists, drawings and replacement

Temperature sensor

7-32
7. Reverse the steps in this procedure to install the power modules.
1. Remove the drive bay.
2. Using a phillips screwdriver, remove the 4 anchor screws securing the CD/hard
drive carrier in the drive bay on both sides.
3. Slide the CD/hard drive carrier out of the front of the drive bay.
4. Using a phillips screwdriver, remove (for installation) the four screws securing
the top hard drive in the CD/hard drive carrier on both sides.
5. Slide the top hard drive out of the back of the CD/hard drive carrier.
6. Using a phillips screwdriver, remove the screw securing the temperature sensor
to the back left of the hard drive.
ApexPro™ Telemetry
See Drive bay on page 7-16.
018A
160A
063A
069A
2001989-203C
