Binks JGX-502 Operation Manual

Important：Read and follow all instructions and SAFETY PRECAUTIONS before using this equipment
Description
The JGX-502 Spray Gun is a conventional air spray gun, patterned after the JGA series, whose functions are similar to
standard air spray gun models. The gun is available in three types: gravity feed, suction feed, and pressure feed, in order to
cover the widest range of applications.
With all areas of the fluid passages made from stainless steel, the JGX-502 can be used with a wide range of paints, with the
only exception being those of a highly corrosive and/or abrasive nature. The use of such materials will require thorough
cleaning and frequent part replacement.
Any questions regarding the operation of the JGX Spray Gun should be directed to us or our distributors BEFORE use.
MODELS
JGX-502 - Air Cap No. - Fluid Tip Size – Type of Feed
(Ex.)： JGX-502-143-FF-G
This represents a gun with a number 143 Aircap, a Size FF Fluid Tip, and set up for Gravity Feed.
SPECIFICATIONS
Air and Fluid Inlet Threads：
Fluid Suction/Pressure Feed
PF3/8 Male, standard
PF1/4 Male, Optional
Air Inlet PF1/4
Weight Suction/Pressure Feed
OPERATION
Before using the gun, the needle packing, which is shipped loose to avoid binding, should be adjusted.
The packing gland (Part#7) should be gradually screwed clockwise while triggering the gun up to the point where the needle
does not smoothly return to the closed-position. At this point the packing gland should be slightly loosened by screwing it in
counter-clockwise so that needle moves freely.
Adjust the atomizing air pressure to the lowest level possible and commensurate with proper atomization quality desired, to
minimize overspray and maximize paint transfer efficiency.
The spray gun should be used at all times perpendicular to the surface to be coated at a distance of 150-200mm.
JGX-502 Spray Gun
Operation Manual
440g
1
