Product Description
Safety Instructions
Operating Instructions
Airless Spray Gun HAP 50
These operating instructions are part of the equipment. Please read and follow all
instructions and safety precautions before using the equipment. Disregarding can
causes injuries on people and/or damages on the unit.
ITW Oberflächentechnik GmbH & Co. KG
Justus-von-Liebig-Straße 31, 63128 Dietzenbach, Deutschland
Telefon +49 (0) 6074 / 403-1
ITW Finishing Systems and Products
Ringwood Road, Bournemouth BH11 9LH, England
Phone +44 (0) 1202 / 571111 Telefax +44 (0) 1202 / 581940
Internet
163-171 Avenue des auréats BP 1453, 26014 Valence Cedex France
Téléphone +33 (0) 4 7575 2700 Fax +33 (0) 4 7575 2799
Internet
for
BINKS
Telefax +49 (0) 6074 / 403-281
Internet
www.itw-finishing.de
www.itweuropeanfinishing.com
ITW Surfaces et Finitions
www.itweuropeanfinishing.com
Edition 10/05
Advertisement
Table of Contents
Related Manuals for Binks HAP 50 Series
Summary of Contents for Binks HAP 50 Series
- Page 1 Product Description Safety Instructions Operating Instructions BINKS Airless Spray Gun HAP 50 These operating instructions are part of the equipment. Please read and follow all instructions and safety precautions before using the equipment. Disregarding can causes injuries on people and/or damages on the unit.
-
Page 2: Table Of Contents
Table of Contents Description....................3 Safety Precautions ..................4 Legal Requirements ................5 Gun Design ....................6 Selection Chart for Strainers ..............6 Strainer Replacement – Disassembly............6 Selection Chart for Spray Tips..............7 Tip Grip Protection for High Pressure Guns ..........7 Accessories .....................8 Gun Connection..................8 Application Technique ................9 Cleaning and Maintenance Procedures ..........9 Exploded View and Spare Parts List HAP 50 D........10 Exploded View and Spare Parts List HAP 50 F ........12... -
Page 3: Description
High Pressure Spray Gun HAP 50 D and HAP 50 F Very tough Airless Manual Spray Gun with 4-finger pull. With wear resisting shut-off valve made of hard metal. Material inlet at the bottom of the gun handle = swivel joint 1/4" NPS (M). Suitable for waterborne coatings. -
Page 4: Safety Precautions
Safety Precautions The Airless Spray Gun HAP 50 corresponds to state-of-the-art technology and meets with the general requirements of EC Rules. This is documented by the attached EC Declaration of Conformity and the CE mark. The High Pressure Gun HAP 50 was designed according to state-of-the-art technology. The gun was tested and operationally reliable prior to leaving our plant. -
Page 5: Legal Requirements
Only use genuine BINKS replacement parts for Airless spray equipment! The use of other than BINKS parts void all warranties ! In case you wish to apply unknown strong acids or aluminum corroding materials, we recommend to contact your local distributor or our company to ensure safe operation. -
Page 6: Gun Design
Gun Design The gun is of a very tough design, however it must not be used as a tool, e.g. to close drums. The Airless Spray Gun HAP 50 is designed for a maximum operating pressure of 500 bar. It comes standard with a swivel joint. -
Page 7: Selection Chart For Spray Tips
Selection Chart for Spray Tips Bore Flow Rate approx. Width Angle ltrs. Water/min. at 70 bar 100 bar Standard Tips Super ZIP Tips 94-98-0030023 0,23 30° 0,13 0,29 94-98-0040023 0,23 40° 0,13 0,29 94-98-0060023 0,23 60° 0,13 0,29 94-98-0040028 90-98-0059411HP 0,28 40°... -
Page 8: Accessories
Accessories Standard Spray Tip - Order No. 94-98-00... (for size see selection chart) Adjustable Tip - Order No. JACT-... (for size see selection chart) Super ZIP Tip - Order No. 90-98-0059... (for size see selection chart) Tip base for Standard Tip - Order No. -
Page 9: Application Technique
The gun must be hold with the whole arm. The BINKS Airless Spray Gun has been factory tested. The unit comes assembled except for the selected tip which must be installed. We recommend, however, to perform the following steps: 1. -
Page 10: Exploded View And Spare Parts List Hap 50 D
Ersatzteilliste / spare parts list Ersatzteile / spare parts HAP 50 D Pos. Bestell Nr. Bezeichnung Description Order no. 0114-013514 Airless HAP 50 D Drehgelenk 1/4" Airless gun HAP 50 D swivel 1/4" Vorbehaltlich technischer Änderungen Page 10... - Page 11 Ersatzteilliste / spare parts list Ersatzteile / spare parts HAP 50 D Pos. Bestell Nr. Bezeichnung Description D / R Order no. 0114-013514 Airless HAP 50 D Drehgelenk 1/4" Airless gun HAP 50 D swivel1/4" 0114-013612 Ventilsitz valve seat 0114-013825 Dichtung gasket 1 / 1 0114-014051 Ventilnadel...
-
Page 12: Exploded View And Spare Parts List Hap 50 F
Ersatzteilliste / spare parts list Ersatzteile / spare parts HAP 50 F Pos. Bestell Nr. Bezeichnung Description Order no. 0114-014930 Airless HAP 50 F Drehgelenk 1/4" Airless gun HAP 50 F swivel 1/4" Vorbehaltlich technischer Änderungen Page 12... - Page 13 Ersatzteilliste / spare parts list Ersatzteile / spare parts HAP 50 F Pos. Bestell Nr. Bezeichnung Description D / R Order no. 0114-014930 Airless HAP 50 F Drehgelenk 1/4" Airless gun HAP 50 F swivel 1/4" 0114-013612 Ventilsitz kpl. valve seat cpl. 0114-013825 Dichtung gasket...
-
Page 14: Ec Declaration Of Conformity
63128 Dietzenbach Germany As the representative/manufacturer of the items listed below: High-Pressure Spray Gun Model BINKS HAP 50 Declare, under our sole responsibility, that the equipment to which this document relates is in conformity with the following standards or other normative documents:...
