Product Information

H Heating system damage due to frost
When the heating system is not in operation
(e.g. controller switched off, fault shutdown),
there is a risk of it freezing when there is frost.
▶ When shutting down or switching off for extended
periods, drain the heating and drinking water pipes
to the lowest point in order to protect the heating
system from freezing.
H Inspection and maintenance
Regular inspection and maintenance are prerequisites
for safe and energy efficient operation of the heating
system.
We recommend you enter into a contract for the
annual inspection and demand-dependent
maintenance with an authorised installer.
▶ Have work carried out only by an approved installer.
▶ If any faults are discovered, have them remedied
immediately.
2 Product Information
These instructions contain important information regarding safe
operation of the control unit for the system user.
Depending on the software version, the display and menu items shown
in the instructions may differ from those in the control unit.
2.1

Declaration of Conformity

The design and operation of this product conform to European Directives
and the supplementary national requirements. Its conformity is
demonstrated by the CE designation.
You can view the Declaration of Conformity on the internet
( back cover).
2.2

Open Source Software

This product contains proprietary software by Bosch (licensed
according to the Bosch standard licensing conditions) and Open Source
Software (licensed according to the Open Source licensing conditions).
The special provisions stated in the license texts apply for LGPL, reverse
engineering is permitted for these components in particular.
You can find Open Source information on the DVD supplied with the
device.
4
2.3

Product data for energy consumption

The specified product data correspond to the requirements of the EU
Regulation No. 811/2013 which supplements ErP Directive 2010/30/
EU. The class of the temperature controller is required to calculate the
central heating energy efficiency of an integrated system and is for this
reason incorporated into the system data sheet.
Function of the CC 8313
CC 8313 and remote control
Room temperature-dependent, modulating
CC 8313
and outside temperature sensor
Weather-compensated, modulating
Weather-compensated, on/off
CC 8313 and outside temperature sensor and
remote control
Weather-compensated with influence of room
temperature, modulating
Weather-compensated with influence of room
temperature, on/off
1) Classification of the user interface according to EU Regulation 811/2013 for the
identification of system packages
2) Contribution to seasonal energy efficiency for central heating in %
Table 2 Product data with regard to energy efficiency of the user
interface
2.4

Product Description

The modular control system provides the perfect means of adjustment
for boilers and wall mounted boilers equipped with a SAFe burner
control unit to ensure the operating conditions for the specific product
are satisfied.
The control unit controls an EMS oil boiler or EMS gas boiler. As an
option, a modulating boiler circulation pump can be activated via a PWM
signal or a 0...10-V interface.
The standard equipment of the control unit comprises the boiler circuit
or heating circuit with mixer and DHW heating functions. So it can be
perfectly matched with the heating system, the control unit can be
extended by up to four function modules.
No parameter settings are lost in the event of a power failure. When the
power supply is restored, the user interface resumes operation.
Notice regarding systems with several heat sources
The CC 8313 control unit can control systems containing several heat
sources (cascades) in combination with the FM-CM cascade module.
For a description of this function, refer to the technical documentation
for the module.
2.5

Determined use

The control unit controls and monitors heating systems in apartment
buildings, residential complexes and other buildings.
▶ Observe country-specific standards and regulations concerning
installation and operation!
Control 8313 – 6720859552 (2017/03)
1) 1)2)
Class [%]
V 3.0
II 2.0
III 1.5
VI 4.0
VII 3.5
