AudioFetch Express LED Indicators

Power
During boot-up (takes about 35 seconds) the LEDs will sequence through different indications. After
boot-up is complete the normal operating indication is:
Power WiFi
● ●
NOTES: WiFi may blink to indicate activity on the WiFi connection – this is normal
WiFi will remain off if AudioFetch Express is configured for wired-only operation
Quick Troubleshooting:
In Wireless Client mode: If
connect into your existing WiFi network. Things to try or check:
·
Check that your existing WiFi network is on and other devices can connect successfully
·
If your WiFi is configured for Captive Portal (there is a splash screen or login page) then the both MAC
addresses of the AudioFetch Express must be added your network's whitelist of clients allowed to bypass the
captive portal.
·
Try power cycling the AudioFetch Express (as troubleshooting step)
·
Try repositioning the AudioFetch Express or your Access Point/Router to check if WiFi signal strength is weak
·
Check that your WiFi SSID and password are correctly configured in the AudioFetch Express – double check
information provided to AudioFetch when ordered and if necessary re-configure the SSID/password settings
as described in section 11 Changing SSID/password in Wireless Client Mode
Rarely, AudioFetch Express will receive firmware updates (if connected to the internet). During an
update, the yellow status LED will flash irregularly to indicate download in progress followed by the
status LEDs going through a number of different sequences (not described here) and finally the
AudioFetch Express will reboot and return to normal operation. Note that configuration settings are
preserved through this firmware update process.
WiFi Status
Status
○ ● ○
Status-RED
LED
Power
WiFi
Status – RED
Status – GREEN
Status – YELLOW
(Power, WiFi, and Status-GREEN on, all others off)
remains blinking indefinitely, the FetchExpress cannot
Description
On when unit has power
On when WiFi is operating
Blinking indicates WiFi activity
Blinking when no connection to network
Off when connected to network
Off when no connection to network yet
On when connected to network
Normally off
Rarely, indicates firmware update active (on)
Contact AudioFetch support if flashing continuously
