9.7 AUDIO SETTINGS page (gain, microphone, ACE feature, STEREO/MONO mode)
The AUDIO SETTINGS page is used to access three different sets of configurations:
AUDIO GAIN
The AUDIO GAIN section displays current audio status for the channel selected from the drop-down
list, and allows the gain to be adjusted.
ACE (Audio Control and Enhance)
Optional: Enter desired
channel name here
MONO/STEREO OPERATING MODE
Selection Options
Channel 1
Channel 2
Channel 2 is available
only when MONO mode
is configured
Enter desired gain here to
set maximum volume
available in App playback
Adjust gain up if users need
more volume
Adjust gain down if audio is
distorted
22
