Channels Setup Page - Broadcastvision Entertainment AudioFetch Express User Manual

21
To assist in setup, the Doghouse MULTI-BOX SETUP page contains a link to detect and display info
about other boxes present on the LAN. Click the link, and then a notification page will appear for
about 5 seconds while the other boxes are being detected. Then the MULTI-BOX SETUP page will
display again with the list of boxes filled out. See the example below which shows the detection
results for a 3-box system.
When the drop-down selector is used to change the box designation, the list of other boxes is cleared.
In this case just click the detection link again to re-display all the boxes.
After detection, the box setting for each will be displayed as shown above (in the column labeled
"Setting"). When configuring a multi-box system, use the detect link to double-check that all boxes
have different/unique designations. For example, this display of detected boxes indicates a problem
because two boxes are set to the same designation:
In this case, one of the conflicting boxes should be changed to BOX C.
Note that other-box detection works only on networks which fully support SSDP discovery protocol.
Some network configurations do not, in which case use the Doghouse Utility as an alternative to
discover all the boxes on the network and display their box settings.

9.6 CHANNELS SETUP page

The CHANNELS SETUP page shows the installed channel and allows alternate name or number to be
assigned. The "Enable" checkbox can be de-selected to disable the channel - the App will no longer
display the channel when it is un-checked.
The default channel number displayed by the App may be replaced by making an entry in the "Name"
field such as the entry "ESPN" shown in the example below. Although up to 10 characters may be
entered in the Doghouse, the App will display only the first five characters of the channel name entry.
IMPORTANT: The "Save Settings" button must be clicked after any changes are made, otherwise the
new settings will be lost at navigation away from this page or the next power cycle.
