MONO operation:
Two channels will appear in the Channels Setup page
Two mono channels will be available in the AudioFetch App
The Analog input connector must be used – do not use Optical or Digital Coax inputs!
To change the operating mode:
1.
Click the dropdown list and select Stereo or Mono choice
2.
Click the Save button
3.
Click the OK button in the confirmation dialog box
When the mode is changed and Save/OK buttons clicked, the new mode will be saved and the
AudioFetch Express will automatically reboot, which will take about 45 seconds. During this time do
not remove power from the AudioFetch Express.
When configured for MONO operation, the Analog input connector must be used, do not use Optical
or Digital Coax inputs. The Analog input connector is a standard 3.5mm stereo jack, in mono mode
the signal coming in on what is usually the Left connection (in stereo operation) will be directed to
Channel 1 in the App, the signal coming in on what is usually the Right connection will be directed to
Channel 2 in the App. Choose the appropriate cables and adapters to route the separate source audio
signals into the L/R signals of the Analog input connector. Contact AudioFetch Support if further help
is required for making the signal connections.

9.8 SYSTEM STATUS page

The SYSTEM STATUS page shows basic information about the system and connected users (see
example on next page). Not all information is refreshed automatically, click the "Refresh" button at
the bottom of the page to update the display of latest status.
26
Selection Options
Stereo
(default)
Mono
Changes not saved until
the Save button is clicked
