User's Guide
LX HD Wall Mount Pivot
< 50 lbs. (22.7 kg)
Features & Specifi cations
- 5˚
± 20˚
English
+ 15˚
For the latest User Installation Guide please visit: www.ergotron.com
English, Español, Français, Deutsch, Nederlands, Italiano, Svenska, 日本語, 汉语
www.ergotron.com |
|
|
|
USA: 1-800-888-8458
Europe: +31 (0)33-45 45 600
China: 400-120-3051
Japan: japansupport@ergotron.com
888-45-198-W-01 rev.C • 12/18
1 of 12
Advertisement
Related Manuals for Ergotron 888-45-198
Summary of Contents for Ergotron 888-45-198
- Page 1 Features & Specifi cations - 5˚ ± 20˚ English + 15˚ For the latest User Installation Guide please visit: www.ergotron.com English, Español, Français, Deutsch, Nederlands, Italiano, Svenska, 日本語, 汉语 www.ergotron.com | USA: 1-800-888-8458 Europe: +31 (0)33-45 45 600 China: 400-120-3051 Japan: japansupport@ergotron.com...
-
Page 2: Tools Needed
Any time equipment is added or removed from this product, resulting in a change in the weight of the mounted load, you should repeat these adjustment steps to ensure safe and optimum operation. 2 of 12 888-45-198-W-01 rev.C • 12/18... - Page 3 Wood Concrete Ergotron product 1/8" 10-24 x 5/8" Stud Finder Concrete Wall Mounting Wood Stud Mounting Ø 3/16" (5mm) Ø 3/8” (10mm) NOTE: Wall Track and Brackets sold separately. 888-45-198-W-01 rev.C • 12/18 3 of 12...
- Page 4 Wood Ø 3/16" (5 mm) M8 x 80mm CAUTION: Make sure the wall mount bracket is level, fl ush and snug to the wall surface. DO NOT OVERTIGHT- EN THE BOLTS. 13 mm 4 of 12 888-45-198-W-01 rev.C • 12/18...
- Page 5 If you drill into an area of concrete that is not solid, reposition mounting holes until both anchors can be fully inserted Ø 3/8" into solid concrete! (10 mm) 3-1/8" (80 mm) 888-45-198-W-01 rev.C • 12/18 5 of 12...
- Page 6 Consult a construction professional if you have any doubt about what this means in regard to your particular situation. 6 of 12 888-45-198-W-01 rev.C • 12/18...
- Page 7 M4 x 8mm 360° 0° Check size of TV/Monitor hole TV/Monitor Hole VESA Adapter Pattern Sizes Confi gurations pattern 100mm (3-15/16”) 75mm (2-15/16”) 75x75mm 100x100mm 100mm (3-15/16”) 100x200mm 200mm (7-7/8”) 200x200mm 200mm (7-7/8”) 200x100mm 888-45-198-W-01 rev.C • 12/18 7 of 12...
- Page 8 Mount Type A TV/Monitor to Arm 75x75mm 100x100mm 100mm (3-15/16”) 75mm (2-15/16”) 75 x 75mm 100 x 100mm M4 x 12mm M4 x 12mm 8 of 12 888-45-198-W-01 rev.C • 12/18...
- Page 9 M5 x 12mm M6 x 12mm NOTE: To reduce M8 holes for use with M5 screws, or if you have a model with Samsung holder rings, follow the M8M5 KIT instructions on the next page. 888-45-198-W-01 rev.C • 12/18 9 of 12...
- Page 10 Install M8M5 reducer bushing to TV/Monitor then use M5 x 20 mm monitor screws and Samsung holder ring to secure. M5 x 20mm TV/Monitor Mounting M8 size hole Holder Ring (Not included *Samsung Only) 10 of 12 888-45-198-W-01 rev.C • 12/18...
- Page 11 Tilt – Forward and Backward - 5˚ Loosen knob, tilt Display to desired position then retighten knob. + 15˚ 888-45-198-W-01 rev.C • 12/18 11 of 12...
- Page 12 Break • 2 to 3 minutes every 20 minutes • 15 to 20 minutes every 2 hours. For Warranty visit: www.ergotron.com/warranty For Service visit: www.ergotron.com For local customer care phone numbers visit: http://contact.ergotron.com NOTE: When contacting customer service, reference the serial number. www.ergotron.com | USA: 1-800-888-8458...
