Service guide
6.
Spare parts list for
PAHT G 20-32
Pos.
Qnt.
Designation
1
1 Housing
2
2 Pin Ø4 x 14
5
10 Screw M8 x 16
9
1 O-ring Ø102 x 3
11
1 End cover CW
31
1 Swash plate
32
1 Screw Ø8 x 16
34
2 Pin Ø4 x 14
61
1 Cylinder barrel
62
1 Spring
63
1 Retainer
64
1 Retainer ball
65
1 Retainer plate
66
9 Piston
67
1 Key 8 x 7 x 32
91
1 Port plate
92
1 Valve plate
93
9 Back up ring
94
9 O-ring Ø13 x 2
121
1 Port flange
122
1 O-ring Ø102 x 3
123
1 O-ring Ø59,5 x 3
124
1 Shaft sealing
125
1 End cover
126
1 Pin Ø5 x 10
127
6 Screw M8 x 60
128
4 Screw M8 x 50
1 Service instruction
Disassembling and assembling PAHT / PAHT G 20-32
Material
AISI 316
AISI 304
AISI 304
NBR
AISI 316
AISI 431
AISI 304
AISI 304
AISI 431
AISI 304
PEEK
AISI 304
1.4301
AISI 431 / PEEK
AISI 316Ti
AISI 304 / PEEK
AISI 431
PTFE
NBR
AISI 316
NBR
NBR
AISI 304 / NBR
AISI 316
AISI 304
AISI 304
AISI 304
180R9175 / 521B1108 / DKCFN.PI.012.E3.02 / 01.2016
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
21
