Chapter 3: Getting Started

Triad Freeze Dry System Components
Locate the model of freeze dry system you received in the following table.
Verify that the components listed are present and undamaged.
If you did not receive one or more of the components listed, contact
Labconco Corporation immediately for further instructions.
Description
Catalog #
7400030 Triad Freeze Dryer System
7400040 Triad Freeze Dryer System
7400060 Triad Freeze Dryer System
7400070 Triad Freeze Dryer System
Plus the following:
Part # Qty.
7373300 1
7373436 1
1488800 2
1291000 1

Setting Up Your Triad Freeze Dry System

Component Orientation and Hose Connections
A minimum of 3" should be allowed between the back of the freeze dry
system and the adjacent wall surface and between the sides of the freeze
dryer and the adjacent wall surfaces. Restriction of the airflow through the
cabinet during operation could adversely affect performance.
Position the vacuum pump near the vacuum exhaust port on the rear of the
cabinet. Attach the supplied hose to the exhaust port using the clamp
provided. Attach the other end of the hose to the inlet fitting on the vacuum
pump. Secure with the clamp provided. The hose may be cut to proper length
to allow for gentle bends without kinks.
Connect the power cord from the vacuum pump into the outlet on the back of
the unit. If your vacuum pump power cord does not have a female IEC plug,
replace the cord end with the female IEC plug provided with the unit (Part
number 1291000).
8 Product Service 816-333-8811 or 1-800-522-7658
Volts
230
230
230
230
Component Description
User's Manual
Tubing
Clamp
Female IEC Plug
Power Cords
Hz
50 X
60 X
50 X
50 X
