powersoft MiniMod 4 User Manual page 17

Pin# Name IN OUT POWER
25 PROTECT 12 P
26 VOUT2MON P
27 GND
28 IN 2 - P
29 IN 2 + P
30 GND
31 +5VDC OUT
32 RESERVED
33 READY 12 P
34 SDPWS P
Range
Level 1 (4.5V to 5V) not in
protection. Level 0 (0V to 0.5V) in
Protection
P
Unbalanced: 1,41Vrms for full
output. 8Vrms absolute max input.
Balanced: 0,705Vrms for full
output. 8Vrms absolute max input.
Unbalanced: 1,41Vrms for full
output shorting pin 7 to GND.
8Vrms absolute max input.
Balanced: 0,705Vrms for full
output. 8Vrms absolute max input.
P
+5Vdc out 20mA max current
P
available
Open Collector, high when output
stage is operative
Active High, Logic input 3,3 to
12Vdc
Scale Factor Impedance Tolerance
4,7kΩ
20V/V 4,5kΩ
4,7kΩ
3,1kΩ
9,4kΩ
9,4kΩ
+/-5%
TBD
1kΩ
Description
Channel 1 & Channel 2
Output Stage Protection
Monitor
Channel 2 Output Voltage
Monitor
Ground
Channel 2 Negative
Balanced input. 26dB Input
to Output Overall Gain
Channel 2 Positive
Balanced input. 26dB Input
to Output Overall Gain
Ground
TBD
Powers Supply Shut Down
Connections | 7
