11 : 2.1. PL2 pinout (B3P-VH JST)

Pin# Symbol
1 L
2 n/c
3 N

11 : 2.3. PL1000, PL3000 pinout

Pin# Name IN OUT POWER
1 SDPWS P
2 READY 13 P
3 RESERVED
4 +5VDC OUT
5 AUXVSEL P
6 IN 1 + P
7 IN 1 - P
8 GND
9 VOUT1MON P
10 PROTECT 12 P
11 IOUT1MON P
12 TEMPMON P
13 +12/15VDC OUT
14 -12/15VDC OUT
15 MUTE13 P
16 +VCCMON P
17 -VCCMON P
18 -VCCMON P
19 +VCCMON P
20 MUTE P
21 -12/15VDC OUT
22 +12/15VDC OUT
23 TEMPMON P
24 IOUT2MON P
6 | MiniMod 4 | User guide
Description
AC Mains: phase input
not connected
AC Mains: neutral input
PL1000 pinout (IDC 34p)
Range
Active High, Logic input 3,3 to
12Vdc
high when output stage is
operative 3,9-4,1
+5Vdc out 20mA max current
P
available
Open: select 15V for auxiliary
voltage. Short to ground: select
12V for auxiliary voltage
Unbalanced: 1,41Vrms for full
output shorting pin 7 to GND.
8Vrms absolute max input.
Balanced: 0,705Vrms for full
output. 8Vrms absolute max input.
Unbalanced: 1,41Vrms for full
output. 8Vrms absolute max input.
Balanced: 0,705Vrms for full
output. 8Vrms absolute max input.
P
Level 1 (4.5V to 5V) not in
protection. Level 0 (0V to 0.5V) in
Protection
0-5V
P +12V @ 0,8A or +15V @ 0,6A
P -12V @ 0,2A or -15V @ 0,2A
Active Low, To be pulled to GND
by current sink at least 2mA
20V/V 2V max
20V/V 2V max
20V/V 2V max
20V/V 2V max
Active Low, To be pulled to GND
by current sink at least 2mA
P -12V @ 0,2A or -15V @ 0,2A
P +12V @ 0,8A or +15V @ 0,6A
0-5V

11 : 2.2. PL4 pinout (molex 22-27-2031)

Pin# Symbol
1 GND
2 HOT +12 V, 100 mA max current draw (fan)
3 GND
The PL4 molex plug in intended for connecting a fan whose
activation is driven by the temperature.
Scale Factor Impedance Tolerance
1kΩ
100K
9,4kΩ
9,4kΩ
4,7kΩ
3,1kΩ
20V/V 4,5kΩ
4,7kΩ
8,35A/V 4,7kΩ
100kΩ
4,5kΩ
4,5kΩ
4,5kΩ
4,5kΩ
TBD 1kΩ
8,35A/V 4,7kΩ
Description
Ground connection
Ground connection
Description
Powers Supply Shut Down
TBD
+/-5%
Internal pull-up 10kΩ @
12V
Channel 1 Positive
Balanced input. 26dB Input
to Output Overall Gain
Channel 1 Negative
Balanced input. 26dB Input
to Output Overall Gain
Ground
Channel 1 Output Voltage
Monitor
Channel 1 & Channel 2
Output Stage Protection
Monitor
Channel 1 Output Current
Monitor
NTC sensor tap output
Positive regulated analog
+/-10% section supply (same as
pin 22)
Negative regulated analog
+/-10% section supply (same as
pin 21)
CH1-CH2-CH3-CH4
Output stage disable PWM
Rail Bus Positive Monitor
Rail Bus Negative Monitor
Rail Bus Negative Monitor
Rail Bus Positive Monitor
CH1-CH2-CH3-CH4
Output stage disable PWM
Negative regulated analog
+/-10% section supply (same as
pin 21)
Positive regulated analog
+/-10% section supply (same as
pin 22)
NTC sensor tap output
Channel 2 Output Current
Monitor
