Configuring the Touchscreen
Agilent N4906B Serial BERT, User's Guide, October 2005
5 Select Graphics Options, then Output To, and the desired output
device:
– Monitor for an external monitor
– Notebook for the built-in display
Use the same procedure to switch back to the built-in display.
Configuring the Touchscreen – Reference
This section describes the options of the on-screen keyboard:
Click Set to access the Options menu:
• Move OSK Window
Click this to enable the arrow keys on your actual keyboard. They
can then move the software keyboard.
TI P
You can always move the On-Screen Keyboard window by clicking its
title bar and dragging it.
Additionally, you can switch between different views of the on-screen
keyboard. The following table lists the displayed buttons for the
different views:
Qwerty Full
Qwerty Simple
Qwerty Minimum
Block Full
Block Simple
Block Minimum
Minimum
NOT E Qwerty options mimic the layout of an actual keyboard. Block options
present the letter characters in alphabetical order.
Softkeys Letters Numeric Characters
X X X
X X
X
X X X
X X
X
X
Customizing the Instrument
X
X
X
X
X
X
