Configuring the Touchscreen

Agilent N4906B Serial BERT, User's Guide, October 2005
Configuring the Touchscreen
Configuring the Touchscreen – Procedures
The following procedures help you to configure the touchscreen
according to your personal needs:
Turning the Touchscreen Off/On
This function disables the instrument touchscreen, external keyboard,
and mouse.
1 On the Utilities menu, click Touchscreen Off. The Enable
Touchscreen icon is placed in the upper right hand corner of the
instrument display.
2 Click the Enable Touchscreen icon to enable the touchscreen,
keyboard, and mouse again.
Calibrating the Touchscreen
In normal usage, you should not need to calibrate the touchscreen
display. But, if you feel that it needs to be realigned with the video
display, do the following:
1 If the title bar of the Serial BERT user interface is not visible, select
Title Bar from the Utility menu.
2 Minimize the Serial BERT user interface window.
3 In the system tray, next to the clock in the lower right corner, right-
click the Touchscreen Settings icon to open the menu with the
available options.
4 Select Calibrate, then Device 1, and Normal. A blank screen with a
target appears.
5 Click the target to start the calibration. When the calibration is
complete, the calibration window will close.
