Short name Meaning
SCS 538/16/0 Sanicube Solaris
SCS 538/16/7 Sanicube Solaris
SCS 538/16/16 Sanicube Solaris
HYC 343/19/0 HybridCube
HYC 544/19/0 HybridCube
HYC 544/32/0 HybridCube
GSU S GasSolarUnit with solar heating support
GSU GasSolarUnit without solar heating support
A1 BO 15 bio-e
A1 BO 20 bio-e
A1-BO
A1 BO 27 bio-e
A1 BO 35 bio-e
A1 BG 25-e
A1 BG 25 F-e
A1-BG
A1 BG 40-e
A1 BG 40F-e
1 Cold water
2 Hot water
3 Heating inflow
4 Heating return flow
5 Mixer circuit
6 Circulation circuit
7 Check valve, return valve
7a Gravity brake (for cold/hot water connection)
8 Solar circuit
AMK1 Mixer group
FLG Solaris FlowGuard regulation valve with flow indicator
Flow sensor, Solaris FlowSensor FLS20
FLS20
(flow and flow temperature measurement)
Mi 3-way-mixer with drive motor
P Mixer circuit pump
Mi
P Boiler circuit pump
K
P Tank circulation pump
S1
P Solar panel circulation pump
S2
P Circulation pump
Z
RDS1 Pressure station
RPS3 P2 Mono Solaris control and pump unit
RPWT1 Solaris plate heat exchanger
SK High-performance flat solar panel
SV Safety pressure relief valve
t Flue gas temperature probe
AG
t Outside temperature sensor
AU
t Cylinder temperature sensor
DHW
t Heating inflow temperature probe
V
t Heating return temperature sensor
R
t Mixer circuit flow temperature sensor
Mi
FA ROTEX Solaris RPS3 P2 - 06/2012
7 x Hydraulic system connection
Remark Order No.
16 45 16
16 45 21
16 45 17
14 05 07
14 05 01
14 05 02
GSU 520S-e 15 71 13
GSU 520S F-e 15 71 14
GSU 530S-e 15 71 25
GSU 530S F-e 15 71 26
GSU 320-e 15 70 28
GSU 320 F-e 15 70 29
GSU 535-e 15 71 43
GSU 535 F-e 15 71 48
15 49 27
15 49 28
15 49 29
15 49 50
15 59 30
15 59 31
15 59 40
15 59 41
Optional
Provided by customer
Accessories 16 50 70
Optional
Accessories 15 60 44
16 41 02
Accessories 16 41 07
Supplied with AMK1.
Included in the scope of delivery of the GSU/A1.
Included in the scope of delivery of the RPS3 P2.
Included with RDS1.
Provided by customer
16 20 30
Pressurised solar system 16 41 13
16 20 31
Solaris V21P 16 20 12
Solaris V26P 16 20 10
Solaris H26P 16 20 11
Accessories 15 70 52
Supplied with GSU/A1.
Supplied with GSU/A1BG+ASA1.
Supplied with GSU/A1.
Accessories 15 60 62
