8.1

Basic data

8

Technical data

Dimensions W x T x H
Operating voltage
Tank circulation pump
Max. electrical power consumption of pump
Control unit
Max. electric power consumption of the control unit
Solar panel temperature sensor
Storage cylinder and return flow temperature sensor
Feed temperature and flow sensor (optional)
Table 8-1 Technical data for control and pump unit
Dimensions W x T x H
Operating voltage
Solar panel circulation pump
Max. electrical power consumption of pump
Max. operating pressure
Max. pump capacity
Pressure gauge
Temperature range
Connections
Table 8-2 Technical data for pressure station
Dimensions W x T x H
Max. operating pressure
Temperature range
Connections
Table 8-3 Technical data for plate heat exchanger
CONF Programming socket for software update
FLS
TS
Fig. 8-1
FA ROTEX Solaris RPS3 P2 - 06/2012
FlowSensor
Storage tank temperature sensor
Connection assignment
Control and pump unit RPS3 P2
230 x 815 x 142 mm
Grundfos UPS 15-65 CIL2
20 - 90 W (modulating)
Digital differential temperature controller with text display
RDS1 pressure station
240 x 410 x 130 mm
Grundfos UPS 15-65 CACAO
0 - 120 °C (short-term 160 °C)
4x 1 ¼" female for Ø 22 clamping ring bolt
RPWT1 plate heat exchanger
240 x 410 x 130 mm
0 - 120 °C (short-term 160 °C)
4x 1 ¼" female for Ø 22 clamping ring bolt
TR Return flow temperature sensor
TK Collector temperature sensor
BSK Burner inhibit contact
8 x Technical data
230 V / 50 Hz
2 W
Pt 1000
PTC
FLS 20
230 V / 50 Hz
52 W
6 bar
2 m³/h
0 - 10 bar
6 bar
P1/P2 Operation and booster pump
F1 Fuse
Power Mains supply
