2 Flatpack2 Rectifier
Module Options
The Flatpack2 rectifier is available in various options, offering different performance and
characteristics.
CAUTION:
!
Never install Flatpack2 rectifiers in power shelves with different output voltage than the rectifier's. The rectifier's
output voltage and the power system's output voltage must always be the same.
Device
Hazard
Air Flow
8
Flatpack2 Module Options ~ Overview
241115.200
Flatpack2 Rectifier 24V, 2000W
241115.250
Flatpack2 Rectifier 24V, 2000W WOR
241115.205
Flatpack2 Rectifier 24V, 1800W HE
241115.001
Flatpack2 Rectifier 48V, 1800W
241115.100
Flatpack2 Rectifier 48V, 2000W
241119.100
Flatpack2 Rectifier 48V, 3000W
241115.105
Flatpack2 Rectifier 48V, 2000W HE
241119.105
Flatpack2 Rectifier 48V, 3000W HE
241115.705
Flatpack2 Rectifier 48-60V, 2000W HE
241115.650
Flatpack2 Solar Charger 48V, 1500W HE – (Solar)
241115.805
Flatpack2 Rectifier 110VDC, 2000W HE WOR - (Industrial)
241115.815
Flatpack2 Rectifier 220VDC, 2000W HE WOR - (Industrial)
241115.110
Flatpack2 Rectifier 48V, 2000W BF
241115.115
Flatpack2 Rectifier 48V, 2000W HE, BF
Heat Management ~ Front-to-Back Air Flow
The following Flatpack2 rectifier options are always to be installed
in power systems designed for Front-to-Back Air Flow heat
management.
CAUTION:
!
Do not install rectifiers with Back-to-Front heat management in power systems
designed for Front-to-Back heat management; otherwise the product guaranty
Device
Hazard
becomes invalidated.
Flatpack2 Rectifier 24V, 2000W
Part number 241115.200. Refer to chapter "Specifications
Flatpack2 Rectifier 24V, 2000W" on page 16.
Flatpack2 Rectifier 24V, 2000W WOR
Part number 241115.250. This rectifier's Wide Output voltage
Range is optimized for charging any type of batteries.
Refer to chapter "Specifications Flatpack2 Rectifier 24V,
2000W WOR" on page 17.
User's Guide Flatpack2 Rectifier Modules,
350002.013, 7v0-2010-09
