1 Introduction

The example in Figure 3 represents a typical Flatpack2 PS system for DC power supply of

industrial equipment, in all areas of the industry, power generation and distribution.

The system is fed from an external AC mains supply, and consists of rectifiers in power

shelves, a system controller and DC distribution unit. Battery banks, LVD contactors, etc.

are typically also a part of the system.

The system controller monitors the whole system, and serves as the local user interface.

You can configure the system from computer, installing the MMT application.

Alarm Outputs NC-C-NO

AC Mains Grid

(230VAC or 400VAC)

AC Supply

(Single- or three-

phase)

Figure 3 Typical Flatpack2 PS system for DC power supply of industrial equipment
