- Page 1 RM43596 JBOD User Manual Rackmount Chassis January 2019 Version 1.0 A document provides an overview of product features, functions, architecture, and support specifications...
- Page 2 No license (express or implied, by estoppel or otherwise) to any intellectual property rights is granted by this document. Chenbro disclaims all express and implied warranties, including without limitation, the implied warranties of merchantability, fitness for a particular purpose, and non-infringement, as well as any warranty arising from course of performance, course of dealing, or usage in trade.
-
Page 3: Table Of Contents
RM43596 JBOD Table of Contents Table of Contents ............................... 3 List of Figures ..............................4 List of Tables ............................... 5 Product Overview ..........................6 1-1 System Features Overview ......................7 1-2 Front Panel ........................... 8 1-3 Back Panel ............................ 9 1-4 Front Control Panel ........................ -
Page 4: List Of Figures
RM43596 JBOD List of Figures Figure 1 Overview ............................7 Figure 2 Overview ............................7 Figure 3 Front panel ............................8 Figure 4 Back panel overview ......................... 9 Figure 5 Front control panel ......................... 10 Figure 6 Chassis dimensions ......................... 11 Figure 7 Top cover installation ........................ -
Page 5: List Of Tables
RM43596 JBOD List of Tables Table 1 Chenbro RM43596 specifications ..................... 6 Table 2 Front control panel ......................... 10 Table 3 Slide rail options ..........................12 Table 4 System environmental specifications summary ................13 Table 5 System packaging information ...................... 14 Table 6 Product weight information ...................... -
Page 6: Product Overview
1. Product Overview This chapter provides a high-level overview of the system features and available options. More details for each major sub-system, feature, or option are provided in the following chapters. Table 1 Chenbro RM43596 specifications Feature Description M/B Form Factor... -
Page 7: System Features Overview
RM43596 JBOD 1-1 System Features Overview Figure 1 Over view Figure 2 Over view A. Rack Handle D. Front Control Panel G. Middle Fixed Fan Module B. LCM Display E. 3.5” Storage Drive Bay H. Internal Expander Cards C. Top Cover Latch F. -
Page 8: Front Panel
RM43596 JBOD 1-2 Front Panel Figure 3 Front panel A. Rack Handles C. LCM Display B. Front Control Panel D. Front Hot-Swap Fan Module Product Overview// │... -
Page 9: Back Panel
RM43596 JBOD 1-3 Back Panel Figure 4 Back panel over view A. External Expander Cards D. QIG Label G. Power Button B. CRPS PSU E. UID Button C. Rear Hot-Swap Fan Module F. IPMI Port Product Overview// │... -
Page 10: Front Control Panel
RM43596 JBOD 1-4 Front Control Panel Figure 5 Front control panel Table 2 Front control panel Label ICON Indicator, button, or connector UID Button/LED Power LED System Alarm LED HDD Activity LED LCM Display Page Up Page down Enter Return... -
Page 11: Chassis Dimensions
RM43596 JBOD 1-5 Chassis Dimensions Figure 6 Chassis dimensions Product Overview// │... -
Page 12: Available Rack Mounting Kit Options (Refer To "Installation")
Advisory Note – Available rack and cabinet mounting kits are not designed to support shipment of the server system while installed in a rack. If you chose to do so, Chenbro advises you to verify your shipping configuration with appropriate shock and vibration testing before shipment. -
Page 13: System Level Environmental Specifications
RM43596 JBOD 1-7 System Level Environmental Specifications The following table defines the system level specifications under operating and non-operating environments. Table 4 System environmental specifications summary Parameter Specification Temperature Operating 5º C to 35º C (41º F to 95º F) -
Page 14: System Packaging
1-8 System Packaging The original Chenbro packaging, where the server system is delivered, is designed to provide protection for L6 configuration and tested to meet ISTA (International Safe Transit Association) Test Procedure 1A (2008). The packaging is also designed to be reused for shipment after the system integration has been completed. -
Page 15: System Components Removal And Installation
RM43596 JBOD 2. System Components Removal and Installation RM43596 supports for a variety of different storage option: 96 x 3.5” Hot-Swap SAS/SATA HDD Support for different storage and peripheral options will vary depending on the system model and/or available accessory options installed. -
Page 16: Top Cover Removal And Installation
RM43596 JBOD 2-1 Top Cover Removal and Installation Figure 7 Top cover installation 1. Align the guide pins of this cover with the grooves on the chassis base, and install the cover vertically as shown. (5 guide pins for both side) NOTE: Keep the latch vertical. -
Page 17: External Hot-Swap Hdd Assembly Removal And Installation
RM43596 JBOD 2-2 External Hot-Swap HDD Assembly Removal and Installation Figure 9 3.5” hot-swap HDD assembly installation 1. With the open latch, insert the HDD assembly into the drive bay as shown until the bottom of chassis base. NOTE: Watch out the direction of HDD assembly while inserting. -
Page 18: Figure 11 3.5" Hdd Installation (Tool-Less Type)
RM43596 JBOD Figure 11 3.5” HDD installation (tool-less type) 1. Slide in the HDD until align the anchor point of HDD tray. 2. Push down the HDD when it is secured with a click. Figure 12 3.5” HDD removal (tool-less type) 1. -
Page 19: System Maintenance
RM43596 JBOD 2-3 System Maintenance Figure 13 Installation of whole system into the rack (tool-less type) 1. Push the system all the way into the cabinet by 2 persons or more. 2. Secure the system with thumb screws on both sides as shown. -
Page 20: Fan Module Removal And Installation
RM43596 JBOD 2-4 Fan Module Removal and Installation Figure 15 Front fan module installation (8038) Figure 16 Front fan module installation (8038) 1. Hold the finger grips of fan brackets as shown. NOTE: Ensure that the arrow sticker on the fan is facing the back of the chassis. -
Page 21: Figure 17 Front Fan Module Removal (8038)
RM43596 JBOD Figure 17 Front fan module removal (8038) Figure 18 Front fan module removal (8038) 1. Remove the shock-absorbing pads on the front fan modules. 2. Grasp and press the fan brackets by the finger grips to release the fan module vertically as shown. -
Page 22: Figure 19 Middle Fan Modules Installation (8038)
RM43596 JBOD Figure 19 Middle fan modules Installation (8038) 1. Hold the finger grips of fan brackets as shown. NOTE: Ensure that the arrow sticker on the fan is facing the back of the chassis. 2. Insert the fan module until it is secured with a click. -
Page 23: Figure 21 Rear Fan Modules Installation (8038)
RM43596 JBOD Figure 21 Rear fan modules installation (8038) 1. Hold the latches of rear fan module. 2. Insert the fan module to the rear fan cage until it is secured with a click. Figure 22 Rear fan modules removal (8038) 1. -
Page 24: Internal/External Expander Card Removal And Installation
RM43596 JBOD 2-5 Internal/External Expander Card Removal and Installation Figure 23 Internal expander card installation 1. Align the slot of the internal expander card with the guide pin on the chassis as shown, and install the card vertically until it reaches the Air Max connectors. - Page 25 RM43596 JBOD Figure 17 External expander card installation 1. Slide the external expander card into the chassis as shown. 2. Secure it with a thumb screw clockwise. Figure 17 External expander card removal 1. Loosen the thumb screw anti-clockwise on external expander card.
-
Page 26: Psu Removal And Installation
RM43596 JBOD 2-6 PSU Removal and Installation PSU installation Figure 25 CRPS 1. Grasp the finger grip with your fingers except the thumbs while pressing and holding the PSU latch with 1 thumb. 2. Slide into the chassis until it is secured with a click. -
Page 27: Slide Rail Installation
RM43596 JBOD 2-7 Slide Rail Installation Figure 27 Slide rail installation-1 (84H314610-003) 1. Attach the inner rail to the chassis base while aligning T pins on the side of the system with the slots on the inner rail. Figure 28 Slide rail installation-2 (84H314610-003) 2. -
Page 28: Figure 29 Slide Rail Installation-3 (84H314610-003)
RM43596 JBOD Figure 29 Slide rail installation-3 (84H314610-003) 4. Install the system into the rack by 2 persons or more. / System Components Removal and Installation │... -
Page 29: Backplane
RM43596 JBOD 3. Backplane Each drive tray includes separate LED indicators for drive activity and drive status. Light pipes integrated into the drive tray direct light emitted from LEDs mounted next to each drive connector on the backplane to the drive tray faceplate, making them visible from the front of the system. -
Page 30: Storage Backplane Options
RM43596 JBOD 3-1 Storage Backplane Options RM43596 supports below backplanes: 2 x 24-port 3.5” SAS/SATA SAS29-pin passive backplane (Front) 2 x 24-port 3.5” SAS/SATA SAS29-pin passive backplane (Rear) 8 x 12Gb/s SAS Expander Card (Internal) 2 x 12Gb/s SAS Expander Card (External) ... -
Page 31: 24-Port 12Gb/S Sata/Sas Passive Backplane (Front-Right/Front-Left)
RM43596 JBOD 3-2 3.5” 24-Port 12Gb/s SATA/SAS Passive Backplane (Front-Right/Front-Left) Table 8 Backplane specifications Specification Host Interface Mini SAS HD HDD Interface SAS/SATA Hot-Swap Yes, allows users to replace devices on line LED indicates storage device status Display Error LED - Red (when HDD is error) LED indicates Mini SAS HD Link status Access LED –... -
Page 32: Figure 32 Backplane Front View (Front-Left)
RM43596 JBOD Figure 32 Backplane front view (front-left) . HDD_24 ~ HDD_27 . HDD_34 ~ HDD_39 . HDD_46 . HDD_28 ~ HDD_33 . HDD_40 ~ HDD_45 . HDD_47 Table 9 Connector and pin header function description Drawing Label Connecter Description... -
Page 33: 24-Port 12Gb/S Sata/Sas Passive Backplane (Rear-Right/Rear-Left)
RM43596 JBOD 3-3 3.5” 24-Port 12Gb/s SATA/SAS Passive Backplane (Rear-Right/Rear-Left) Table 10 Backplane specifications Specification Host Interface Mini SAS HD HDD Interface SAS/SATA Hot-Swap Yes, allows users to replace storage devices on line Display LED indicates storage device status Error LED - Red (when HDD is error) LED indicates Mini SAS HD Link status Access LED –... -
Page 34: Figure 34 Backplane Front View (Rear-Left)
RM43596 JBOD Figure 34 Backplane front view (rear-left) . HDD_72 ~ HDD_77 . HDD_84 ~ HDD_89 . HDD_94 . HDD_78 ~ HDD_83 . HDD_90 ~ HDD_93 . HDD_95 Table 11 Connector and pin header function description Drawing Label Connector Description Power The backplane includes two Micro-Fit 3.0mm 2 x 16... -
Page 35: Maintenance And Service
You may need to return the defective item by request. The customer should ensure that the products are Defect On Arrival for up to three months from Chenbro’s shipping date and the damage is not caused by shipping or failures resulting from accident, misuse, abuse, neglect, mishandling, misapplication, modification, improper operation, improper repair or rework.
