HS2016/2032/2064/2128 Alarm Panel
V1.0 User Manual
WARNING: This manual contains information on limitations regarding
product use and function and information on the limitations as to liability
of the manufacturer. The entire manual should be carefully read.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HS2016 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DSC HS2016

Summary of Contents for DSC HS2016

  • Page 1 HS2016/2032/2064/2128 Alarm Panel V1.0 User Manual WARNING: This manual contains information on limitations regarding product use and function and information on the limitations as to liability of the manufacturer. The entire manual should be carefully read.

  • Page 2: Table Of Contents

    Table of Contents 1 Quick Reference 2 About your Security System The HS Series Security System ..............6 2.1.1 Carbon Monoxide Detection (must be enabled by your Installer) ....6 2.1.2 Fire Detection (must be enabled by your Installer) ........6 2.1.3 Testing .......................
  • Page 3 Table of Contents 6.3.1 Using the Keypad to Lookup the Number to Call for SMS Commands ..20 6.3.2 Sending SMS Commands to your System ..........20 6.3.3 SMS Responses from your System ............21 7 Managing Users User Codes ....................22 7.1.1 Access Codes....................
  • Page 4 Table of Contents 12.2.1 System Lockout due to Invalid Attempts............ 37 12.3 Command Outputs..................37 13 Regulatory Agency Statements 14 Installer Warning 15 Safety Instructions 15.1 Regular Maintenance and Troubleshooting..........41 15.1.1 Cleaning..................... 41 15.1.2 Troubleshooting ..................41 16 EULA 17 Locating Smoke and CO Detectors 17.1 Smoke Detectors ..................

  • Page 5: Quick Reference

    1 Q u i c k R e f e r e n c e The HS Series Alarm System uses a menu based navigation system. The scroll keys are used to cycle through the list of actions contained within the current menu. However, many actions can also be accessed using a shortcut key.

  • Page 6: About Your Security System

    2 A b o u t y o u r S e c u r i t y S y s t e m 2.1 The HS Series Security System Your DSC Security System has been designed to provide you with the greatest possible flexibility and convenience. Read this manual carefully and have your installer instruct you on your system's operation and on which features have been implemented in your system.

  • Page 7: General System Operation

    2.1.6 General System Operation Your security system is made up of a DSC control panel, one or more keypads and various sensors and detectors. The control panel will be mounted out of the way in a utility closet or in a basement. The metal cabinet contains the system electronics, fuses and standby battery.

  • Page 8: System Types

    3 S y s t e m T y p e s 3.1 System Models HS2016 16 Zone Alarm System HS2016-4 16 Zone Alarm System HS2032 32 Zone Alarm System HS2064 64 Zone Alarm System HS2128 128 Zone Alarm System 3.2 Keypads...

  • Page 9: Securing The Premises

    4 S e c u r i n g t h e P r e m i s e s 4.1 Arming the System with the Keypad The HS Series provides multiple arming modes as described below: Away mode Use when all members of your household will not be home. Away mode activates all perimeter and interior sensors in the alarm system.

  • Page 10: Stay Arming The System With The Keypad

    4 S e c u r i n g t h e P r e m i s e s 4.1.2 Stay Arming the System with the Keypad Stay mode partially activates your alarm system by: • Arming all perimeter sensors. •...

  • Page 11: No-Entry Arming

    4 S e c u r i n g t h e P r e m i s e s To Arm the System in Night mode What you see Date Time 1. Once the system is armed in Stay mode (Armed indicator is on) at any key- JAN 02/13 2:06a...

  • Page 12: Leaving When The System Is Already Armed - Quick Exit

    4 S e c u r i n g t h e P r e m i s e s 4.2 Leaving when the System is Already Armed - Quick Exit Use the Quick Exit feature if the system is already armed and you would like to leave without disarming and rearming the system.

  • Page 13: Disarming The System

    4 S e c u r i n g t h e P r e m i s e s 4.4 Disarming the system Depending on your system configuration, there are multiple methods you can use to disarm your system. You can disarm the system using a: •...
  • Page 14 4 S e c u r i n g t h e P r e m i s e s Additional bypass features: Recall Last Bypass Recalls all zones that were bypassed the last time the bypass zone feature was used.

  • Page 15: Bypass Groups

    4 S e c u r i n g t h e P r e m i s e s To Clear the Bypass Flag from All Zones (Continued) What you see Scroll to <> 3. Press . If required enter your [access code]. Bypass Zones Press (*) for <>...
  • Page 16 4 S e c u r i n g t h e P r e m i s e s To Load a Bypass Group (Continued) What you see 6. The group of zones are now bypassed. The following message briefly dis- Bypass Group Zones Bypassed plays.

  • Page 17: Emergency Keys And Alarms

    5 E m e r g e n c y K e y s a n d A l a r m s 5.1 Emergency Keys IMPORTANT: EMERGENCY USE ONLY! Pressing both the emergency keys generates a Fire, Medical, or Panic Alarm, and alerts the monitoring sta- tion.

  • Page 18: Carbon Monoxide Alarm - 4 Beeps, Long Pause, 4 Beeps

    5 E m e r g e n c y K e y s a n d A l a r m s 5.3 Carbon Monoxide Alarm - 4 beeps, long pause, 4 beeps WARNING: Carefully review your Carbon Monoxide Alarm Installation/User Guide to determine the necessary actions required to ensure your safety and ensure that the equipment is operating correctly.

  • Page 19: Wireless Keys And Other Devices

    6 W i r e l e s s K e y s a n d o t h e r D e v i c e s In addition to the keypad, the HS Series system can be controlled using a variety of devices: •...
  • Page 20 6 W i r e l e s s K e y s a n d o t h e r D e v i c e s 6.3.1 Using the Keypad to Lookup the Number to Call for SMS Commands The phone number of the system is programmed by the installer.
  • Page 21 6 W i r e l e s s K e y s a n d o t h e r D e v i c e s Table 6-1 SMS Commands (Continued) Commands Notes Activates Output 2. Activate Command Output 2 Activates Output 3.
  • Page 22 7 M a n a g i n g U s e r s 7.1 User Codes Up to 95 different users can be programmed in the HS Series. Each user can be: • Uniquely labeled. • Assigned an access code. •...
  • Page 23 7 M a n a g i n g U s e r s 7.1.1 Access Codes Each configured user is assigned a number from 01-95. When creating access codes the following criteria applies: • Codes cannot be duplicated. • New codes must differ from existing codes by more than one digit (e.g., if 1234 exists, 1235 is invalid).
  • Page 24 7 M a n a g i n g U s e r s To Delete a Proximity Tag What you see Press (*) for <> 1. From the User Codes menu press scroll to Prox Tag and Prox Tag press 2.
  • Page 25 7 M a n a g i n g U s e r s To Edit a User Label (Continued) What you see Program Name 2. Use the arrow keys to move the cursor to a blank space or existing {User 1 Label} character.
