This installation guide provides the basic wiring, programming and troubleshooting information required to install the PowerSeries Neo alarm controller. Use this guide in conjunction with the PowerSeries Neo
Reference Manual available online from the DSC website at www.dsc.com. Available models: HS2016, HS2032, HS2064, HS2128.

Quick Setup

1
Plan
Plan the installation including all alarm detection devices,
zone expanders, keypads and other required modules.
2
Mount
Decide on a location for the alarm panel and secure it to
the wall using suitable mounting hardware.
3
Wire
Complete all wiring including modules, zones,
bells/sirens, telephone line connections and ground
connections. Record module serial numbers on page 20.
4
Power
Connect the battery and power up the system. The battery
must be connected.
5
Enroll
Hardwired: Wire the keypad to the Corbus, power up the
First
alarm panel then press any button on the keypad.
Keypad
Wireless: Wire the HSM2Host to the Corbus, then
power up the alarm panel and a wireless keypad. Press
any button on the keypad to enroll it. The HSM2Host is
then enrolled on the alarm panel. Alternately, enroll an
RF keypad.
6
Enroll
[*][8][Installer Code][902] subsection [000]. Press [*] to
begin auto-enrollment. Module slots are automatically
modules
assigned. Use scroll keys to view slots. Change slot by
typing a 2-digit number.
7
Enroll
[*][8][Installer Code][804] subsection [000]. Note: An
wireless
HSM2HOST or RF keypad must be enrolled first.
devices
8
Program Basic programming: [*][8][installer code] [001]/[002]>
Zone Type/Zone Attribute [005]>[001] Partition 1
Timers: – Entry Delay 1 – Entry Delay 2 – Exit Delay
[301]>[001] Phone #1 [310]>[000] System Account
Code
9
Test
Test the panel completely to ensure that all features and
functions operate as programmed. – [901] Walk Test –
[904][000] Wireless Placement Test

Compatible Devices

Throughout this document, x in the model number represents the
operating frequency of the device as follows: 9 (912-919 MHz), 8
(868MHz), 4 (433MHz).
Note: Only models operating in the band 912-919 MHz are UL/ULC
UL
listed where indicated. Only
UL/ULC listed systems.
Table 1-1 Compatible Devices
Modules
Wireless keypads:
Hardwired keypads with 2-way wireless integration
module:
Hardwired keypads:
Touchscreen Keypad
WARNING: This manual contains information on limitations regarding product use and function and information on
the limitations as to liability of the manufacturer. The entire manual should be carefully read.
Alarm Controller v1.1 Installation Guide
approved devices are to be used with
UL
HS2LCDWFx
HS2LCDWFPVx
UL
HS2LCDWFPx
UL
HS2LCDRFx
HS2ICNRFx
UL
HS2LCDRFPx
HS2ICNRFPx
UL
UL
HS2LCD
HS2ICNP
UL
UL
HS2LCDP
HS2LED
UL
HS2ICN
HS2TCHP
Note: For ULC-s559 Listed applications
the HS2TCHP touch screen keypad is for
supplementary use only.
2-way wireless integration module:
8-zone expander:
8-output expander:
Power supply:
4 high current output expander:
Alternate communicator:
Hardwired Devices
2-wire smoke detectors:
y= A, B, or C
A: ULC listed models
B: UL listed models
C: European and Australian models
4-wire smoke detectors:
y= A, B, or C
A: ULC listed models
B: UL listed models
C: European and Australian models
CO detectors:
Wireless Devices
Wireless PG smoke detectors
Wireless PG smoke and heat detector
Wireless PG CO detector:
Wireless PG PIR motion detectors:
Wireless PG PIR + camera motion detector
Wireless PG curtain motion detector
Wireless PG dual tech motion detector
Wireless PG mirror motion detector
Wireless PG outdoor motion detector
Wireless PG glass break detector:
Wireless PG shock detector:
Wireless PG flood detector:
Wireless PG temperature detector (indoor use):
Outdoor temperature probe (requires PGx905)
Wireless PG keys:
Wireless PG panic key
Wireless PG 2-button key
Wireless PG sirens:
Wireless PG repeater:
Wireless PG door/window contacts:
Wireless PG door/window contact w/ AUX
Central Station Receivers
UL
SG-System I, II, III, IV
UL
Enclosures
UL
PC5003C, PC4050CR (ULC Fire Monitoring), PC4050CAR (UL Commercial Burg), CMC-1(UL
Commercial Burg) Other enclosures are available to suit a variety of system configurations.
UL
HSM2HOSTx
HSM2108
UL
UL
HSM2208
HSM2300
UL
UL
HSM2204
UL
UL
3G2080
TL2803G
UL
3G2080R
TL2803GR
UL
TL280
UL
PCL-422
UL
UL
TL280R
UL
FSA-210x
FSA-210xR
UL
UL
FSA-210xT
UL
FSA-210xRT
UL
UL
FSA-210xS
FSA-210xRS
UL
UL
FSA-210xST
FSA-210xRST
UL
UL
FSA-210xLST
FSA-210xLRST
UL
UL
FSA-410x
FSA-410xR
UL
UL
FSA-410xT
FSA-410xRT
UL
UL
FSA-410xS
FSA-410xRS
UL
UL
FSA-410xST
FSA-410xRST
UL
FSA-410xLST
FSA-410xLRST
UL
UL
UL
CO-12/24
FW-CO1224
UL
UL
12-24SIR
CO1224
UL
FW-CO12
UL
PGx926
UL
PGx916
UL
PGx916
UL
PGx904(P)
UL
PGx934(P)
UL
PGx924
PGx984(P)
UL
PGx974(P)
UL
PGx994
PGx912
UL
PGx935
UL
PGx985
UL
PGx905
PGTEMP-PROBE
UL
PGx939
UL
PGx929
UL
PGx938
UL
PGx949
UL
PGx901
UL
PGx911
UL
PGx920
UL
PGx975
UL
PGx945
