Getting Started This chapter describes how to unpack and identifying components on the device. Unpacking It is a good idea to save the packaging materials and shipping box in case that machine needs to be returned for service. Please un-pack and re-pack the machine terminal as shown below.
Connector Pin Define This section describes the connectors pin define. COM Connector Pin Define Signal Signal +5V/ +12V *It could be supplied with power with 5V or 12V via Jumper or BIOS-setting. VGA Connector Pin Define Signal Signal Signal AGND Green AGND DDC DAT...
Page 15
LAN Connector Pin Define Signal Signal TXA+ TXC- TXA- TXB- TXB+ TXD+ TXC+ TXD- RJ-11 Cash Drawer Connector Pin Define Signal CASEOPEN2 CASH1 CASEOPEN1 CASH2 *Voltage is selected via JP1 DC 12V Input Connector Pin Define Signal COM Connector Pin Define Signal Signal SOUT...
Page 16
USB 12V connector pin define Signal Signal +12V USB + +12V USB - USB Vcc USB 24V connector pin define Signal Signal +24V USB + +24V USB - USB Vcc Parallel connector pin define Signal Signal Signal Strob# Acknowledge# Data 0 Busy Data 1 Paper Empty#...
Mainboard Connectors connector to connector to connector to USB PCBA speaker power button connector to LED cable connector to touch panel connector to SATA HDD connector to HDD power connector to MSR PCBA connector to connector to VGA port LVDS cable...
Page 20
SATA Connector Pin Define Signal Signal SATA_RX- SATA_TX+ SATA_RX+ SATA_TX-...
BIOS Setup The primary function of the BIOS (Basic Input and Output System) is to identify and initiate component hardware. The BIOS parameters are stored in non-volatile BIOS memory (CMOS). CMOS contents don’t get erased when the computer is turned off. About the BIOS Setup Utility The BIOS Setup Utility enables you to configure the following items: •...
Entering the Setup Utility When you power on the system, BIOS enters the Power-On Self Test (POST) routines. POST is a series of built-in diagnostics performed by the BIOS. After the POST routines are completed, the following message appears: Press DEL to run Setup Press the delete key <Delete>...
Main Screen This screen includes System BIOS Information, Processor, System memory and displays the System Time and System Date. System Overview This screen displays System BIOS Information, Processor, System memory, System Time and System Date. System Time/ System Date The System Time and System Date items show the current date and time held by the machine. To set the time and date use the Tab key to move from field to field.
Advanced Settings This setup screen includes sub-menus for APCI Configuration, CPU Configuration, SATA Configuration, USB Configurations, Super IO Configurations and Hardware Health Configuration. CPU Configuration Intel (VMX) Virtualization Technology This feature allows you to enable or disable Intel VMX (Virtual-Machine Extensions) Virtualization Technology support that can utilize the additional hardware capabilities provided by Vanderpool Technology.
Page 25
PCH-FW Configuration This screen displays the information of PCH firmware, such as the firmware version, mode, SKU, integrity value, and status. ACPI Settings Enable Hibernation This item allows user to enable or disable the hibernation feature for OS. This option may be not effective with some OS.
Page 26
Soft-Off by PWR-BTTN Under ACPI (Advanced Configuration and Power management Interface) you can create a software power down. In a software power down, the system can be resumed by Wake Up Alarms. This item lets you install a software power down that is controlled by the normal power button on your system.
Page 27
Serial Port X Configuration Serial Port x This item allows you to enables or disables a serial port. Change Settings This item allows you to specific IO address and IRQ for the serial port.This item allows you to specific IO address and IRQ. Parallel Port Configuration Parallel Port This item allows you to enables or disables the parallel port.
Page 28
Hardware Monitor This screen displays the information of the computer health status Network Stack Configuration Network Stack This item allows you to enables or disables the UEFI network stack. Ipv4 PXE Support This item allows you to enables or disables IPv4 PXE boot support. When disabled, IPv4 PXE boot support will not be available.
Page 29
Ipv6 Configuration Policy This item allows you to set the IP6 configuration policy. PXE boot wait time This item allows you to abort the PXE boot by pressing the ESC key for a specific wait time. Media detect count This item allows you to check the media for a specific number of times. CSM Configuration CSM Support Use this item to enable or disable CSM support.
Page 30
eMMC Configuration eMMC Controller This item allows you to enables or disables eMMC device supported. eMMC Controller This item allows you to enables or disables the SCS eMMC 5.0 HS400 mode. SDIO Access Mode This item allows you to set SD device access mode: •...
Chipset Settings This screen allow you to configure the chipset options. Graphics Configuration GTT Size This field allows you to select how much system memory can be allocated to GTT. Aperture Size This field allows you to select how much system memory can be allocated to graphics chip for video purposes.
Page 32
LCD Control This sub-menu allows you to set up the LVDS control. Memory Information PCH-IO Configuration PCI Express Configuration This sub-menu allows you to set up the PCI express configuration. SATA And RST Configuration This sub-menu allows you to set up the SATA and RST configuration. USB Configuration This sub-menu allows you to set up the USB configuration.
Page 33
Mini-PCIE USB Support This item allows you to enable or disable the Mini-PCIE USB signal. LAN1 / LAN2 Wake This feature allows you to enable or disable the Wake on LAN function. LED S3 Function This feature allows you to enable or disable the LED S3 blinking feature. USB Maintain Port This feature allows you to enable or disable the USB maintain port.
Security Settings This screen allows you to configure the system security settings. Create or Change Adminitrator/ User Password An administrator password takes precedence over a user password, and the administrator can limit the activities of a user. To create or change a password, follow these steps: Highlight the item Administrator/ User Password on the Security menu and press <Enter>.
Boot Settings This screen allow you to configure the boot options. Setup Prompt Timeout Number of seconds to wait for setup activation key. 65535 (0xFFFF) means indefinite waiting. Bootup Numlock State This item is used to select the Power-on state for Numlock. FullScreen Logo This item enables you to show the full screen logo on the bootup screen.
Save & Exit This screen allows you to load default setting values, save changes and discard changes. Save Changes and Reset Highlight this item and press <Enter> to save the changes that you have made in the Setup Utility and restart the system. When the dialog box appears, press <Yes> to save and exit, or press <No>...
Installing Drivers and Software This section explains how to install the included drivers and software. Intel Chipset Driver The Intel Chipset Device Software updates the Windows INF files so that the Intel chipset is correctly configured. Follow these instructions to install the chipset software : Click Next to continue.
Page 38
Read the license agreement, then click Accept. Browse the ReadMe Information, then click Install.
Page 39
The Intel Chipset Software Utility files are installed to the system. When prompted to restart, click Restart Now to restart the system.
Intel Serial IO Refer to the following to install the Serial IO driver. Click Next to continue. Read the license agreement, check “I accept the terms in the License Agreement”. Click Next to continue.
Page 43
Click Next to continue. Click Next to continue.
Page 44
Select Yes, I want to restart my computer now. Then click Finish to restart the system.
Locating the Problem Refer to this section to locate the problem with the drvice. General Checkout Guidelines Use the following procedure to troubleshoot problems: • Identify as many symptoms as possible in detail. • Verify symptoms by recreating them. • Follow the corrective procedures in order.
Refer to the following to prevent incorrect cash drawer status detection by the system: I/O Port Port Condition Note Address High(1) → Close If Bit is set to Low to open Cashdrawer A 05A8 the cash drawer, after it Control port Low(0) →...
Touch Screen Symptoms Symptom Corrective Procedure • Touchscreen does not • Install and run the touchscreen tility from the driver CD. function • Reseat the panel cable. • No virtual mouse • Reseat the touchscreen board-to-touch panel cable. • Cursor doesn’t follow when •...
USB Symptoms Symptom Corrective Procedure • USB device does not function • Check that the USB device is detected in Windows Device Manager. • Reinstall the USB device driver. • Replace the mainboard. Peripheral-Device Symptoms Symptom Corrective Procedure • USB ports do not work •...
Replacing Field Replaceable Units (FRUs) This chapter provides instructions for replacing FRUs. Before You Begin Make sure you have a stable, clean working environment. Dust and dirt can get into components and may cause malfunction. Adequate lighting and proper tools can prevent you from accidentally damaging the internal components.
Panel Rotate the LCD screen forward Remove the screws that secures the base to the panel. CAUTION The screen is fragile. Placing the monitor face-down on a flat, soft area prevents scratches, defacing, or breakage. Disconnect power and HDD cables. Lift the panel and remove it from the base.
Panel Back Cover Before proceeding, remove the following FRUs. • Panel Remove the MSR compartment cover. Remove the screw that secure the customer display compartment cover. Remove the customer display compartment cover.
Page 55
Remove 9 screws from the panel back cover. Open the panel back cover and remove SATA cables, HDD power cable and Wi-Fi antenna cable.
MSR PCBA Before proceeding, remove the following FRUs. • Panel • Panel Back Cover Remove two screws that secure the MSR PCBA. Disconnect the cable from the mainboard. Remove the MSR PCBA.
Power Button Before proceeding, remove the following FRUs. • Panel • Panel Back Cover Remove 2 screws hat secure the power button bracket. Disconnect the cable from the mainboard. Remove the power button.
USB PCBA Before proceeding, remove the following FRUs. • Panel • Panel Back Cover Remove 2 screws that secure the USB PCBA. Disconnect the cable from the mainboard. Remove the USB PCBA.
Speaker Before proceeding, remove the following FRUs. • Panel • Panel Back Cover Remove 2 screws that secure the speaker. Disconnect the cable from the mainboard. Remove the speaker. Touch Cable Before proceeding, remove the following FRUs. • Panel • Panel Back Cover Disconnect one end of the touch cable from the...
VGA Port Before proceeding, remove the following FRUs. • Panel • Panel Back Cover Disconnect the VGA port connector. Remove the screw that secures the VGA port grounding wire on the motherboard. Remove the 2 hex screws on either side of the VGA port.
VDSL Cable Before proceeding, remove the following FRUs. • Panel • Panel Back Cover Disconnect the VDSL cable. Remove the screw that secures the VDSL grounding wire on the motherboard. LED Cable Before proceeding, remove the following FRUs. • Panel •...
Mainboard Before proceeding, remove the following FRUs. • Panel • Panel Back Cover Disconnect the MSR PCBA, Power Button, USB PCBA, Speaker, Touch Cable, VGA Port, VDSL Cable and LED cable connectors from the mainboard. Remove all screws from the mainboard. Remove the mainboard.
