Eval-M1-Im818-A Board Specifications - Infineon EVAL-M1-IM818-A User Manual

EVAL-M1-IM818-A User Manual
iMOTION™ Modular Application Design Kit
Main features
3.1

EVAL-M1-IM818-A board specifications

Table 2 depicts the important specifications of the evaluation board EVAL-M1-IM818-A.
Table 2 EVAL-M1-IM818-A board specifications
Parameters
Input
Voltage
Input current
Output
Power (3phases)
Current per leg
DC Bus Voltage
Maximum DC bus voltage
Minimum DC bus voltage
Current feedback
Current sensing resistors RSU,
RSV, RSW
Protections
Output current trip level
Temperature trip level
On board power supply
15 V
3.3 V
PCB characteristics
Material
Dimension
System environment
Ambient temperature
User Manual
Values
380 V
rms
12 A
rms
2600 W
4A
rms
820 V
400 V
25mΩ X 3
20 A
peak
100 °C
15 V ± 5 %, max. 250 mA
3.3 V ± 2 %, max. 200mA
FR4, 1.6 mm thickness, 2 layers.
35 µm copper thickness
195 mm x 140 mm x 70mm
From 0 to 43°C
6
Conditions / comments
±20% VAC input
Input 380 VAC, Ta=25°C, IM818-MCC
Input 380VAC, fPWM=6 kHz, Ta=25°C,
TC=100°C, Natural convection
Input 380VAC , fPWM=6 kHz, Ta=25°C,
TC=100°C, Natural convection
Limited by electrolytic capacitor which
max voltage is 900V
Aux power supply can start
Two 50mΩ in parallel for one leg
Current feedback to controller, so over
current protection level is decided by
controller. This Itrip level for IPM
Internal NTC temperature to controller.
Recommend to set this level for protection
Used for CIPOS™ IPM gate driver and LDO
Supplying the 3.3V to the controller board
Non-condensing, maximum RH of 95 %
<Revision 1.0>
<2018-11-15>
