P HYSIC A L ACC E SS REA DERS
iCLASS SE® and multiCLASS® SE
Magnetic Stripe Readers
INSTALLATION GUIDE
RM40E
RMP40E
ACCESS
RMK40E
RMPK40E
flexibility.
1 3.5 6 M H Z CO N TAC T L ESS A ND 1 2 5 KH Z P R OX I M I T Y C A RD RE A DE RS
instalación
installation
instalação
installation
installazione
安装
取り付け
설치
УСТАНОВКА
PLT-01320, B.1
Advertisement
Table of Contents
Related Manuals for Assa Abloy multiCLASS SE Series
Summary of Contents for Assa Abloy multiCLASS SE Series
- Page 1 instalación installation instalação installation installazione 安装 取り付け 설치 УСТАНОВКА P HYSIC A L ACC E SS REA DERS iCLASS SE® and multiCLASS® SE Magnetic Stripe Readers INSTALLATION GUIDE RM40E RMK40E RMP40E RMPK40E ACCESS flexibility. 1 3.5 6 M H Z CO N TAC T L ESS A ND 1 2 5 KH Z P R OX I M I T Y C A RD RE A DE RS PLT-01320, B.1...
-
Page 2: Parts List
• Alimentatore lineare c.c. • Металлическая или пластмассовая распределительная • Scatola di giunzione metallica o in plastica коробка • Utensile di sicurezza (per viti antimanomissione) HID 04-0001-03 • Спецключ (для защитного винта) HID 04-0001-03 INSTALLATION GUIDE © 2009-2013 HID Global Corporation/ASSA ABLOY AB. All rights reserved. HID 04-0001-03... -
Page 3: Specifications
300 ft - 24 AWG (91 m) RMK40 925N 136 mA 297 mA RMK40Ex RMPK40 925P 160 mA 307 mA RMPK40Ex UL Reference Number Deciphering NSC = Normal Standby Condition Reader Colors: K = Black, G = Gray Wiring: N = Pigtail, T = Terminal INSTALLATION GUIDE © 2009-2013 HID Global Corporation/ASSA ABLOY AB. All rights reserved. - Page 4 Boîtier de jonction non inclus. Caixa de junção não incluída. Anschlusskasten nicht mit inbegriffen. Scatola di raccordo non inclusa. 不包括接线盒。 EMEA Mounting 接続ボックスは含まれていません。 Holes 연결 박스는 제품에 포함되지 않습니다. Распределительная коробка не прилагается Rotate magnetic stripe device to flip card swipe reads. INSTALLATION GUIDE © 2009-2013 HID Global Corporation/ASSA ABLOY AB. All rights reserved.
- Page 5 PLT-01320, B.1 RM40E, RMP40E, RMK40E, and RMPK40E Attach the plugs sealing the reader for outdoor use. INSTALLATION GUIDE © 2009-2013 HID Global Corporation/ASSA ABLOY AB. All rights reserved.
-
Page 6: Electrostatic Sensitive Devices
Drenaje P1-5 Sin uso Verde P2-3 Datos Wiegand 0 / Datos Marrón P1-6 Entrada para LED Rojo Rosa P2-2 GPIO3 (RS485-Z / TXB) Azul P1-7 Entrada de retención Gris P2-1 GPIO4 (RS485-Y / TXA) Salida de sabotaje. Al activarse, la salida se sincroniza con tierra (predeterminado). Depende de la configuración del lector. Consulte las configuraciones de HTOG Wiegand y Clock-and-Data para obtener más información. INSTALLATION GUIDE © 2009-2013 HID Global Corporation/ASSA ABLOY AB. All rights reserved. - Page 7 Non usato Verde P2-3 ** Wiegand Data 0 / Clock Marrone P1-6 Ingresso LED rosso Rosa P2-2 GPIO3 (RS485-Z / TXB) P1-7 Ingresso di tenuta Grigio P2-1 GPIO4 (RS485-Y / TXA) Uscita tamper. Quando attivata, uscita a negativo (predefinito). Dipende dalla configurazione del lettore. Per ulteriori informazioni in merito vedere le configurazioni HTOG Wiegand e Clock-and-Data. INSTALLATION GUIDE © 2009-2013 HID Global Corporation/ASSA ABLOY AB. All rights reserved.
- Page 8 Wiegand Data 1 / Clock Отвод P1-5 Не используется Зеленый P2-3 Wiegand Data 0 / Data Коричневый P1-6 Вход управления красным светодиодом Розовый P2-2 GPIO3 (RS485-Z / TXB) Синий P1-7 Вход задержки Серый Сланец P2-1 GPIO4 (RS485-Y / TXA) Выход датчика вскрытия корпуса. После активации датчика выход замыкается на землю (по умолчанию). Зависит от конфигурации считывателя. Дополнительная информация приводится в руководстве по заказу изделий Wiegand и Clock-and-Data. INSTALLATION GUIDE © 2009-2013 HID Global Corporation/ASSA ABLOY AB. All rights reserved.
-
Page 9: Power & Testing
Mettez sous tension Pruebe la tarjeta Ligue a energia Testez la carte Einschalten Teste o cartão Accendere Karte testen 打开电源 Provare la tessera 電源を入れます 测试卡 전원을 켜십시오 カードをテストします Включить питание 카드를 테스트하십시오 Протестировать чтение карты INSTALLATION GUIDE © 2009-2013 HID Global Corporation/ASSA ABLOY AB. All rights reserved. - Page 10 Connect only to a Listed Access Control / Burglary power-limited power supply. These readers are intended to be used with listed (UL294) control equipment. Only Wiegand and RS-485 communications have been evaluated by UL. CAUTION: Any changes or modifcations to this devise not explicitly approved by the manufacturer could void your authority to operate this equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interfer- ence received, including interference that may cause undesired operation. Canada Radio Certification This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : (1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. The carrier frequency output power are as follows: RMP40E and RMPK40E - 125 KHz < - 14 dBµV/m @ 300 meters CE Marking HID Global hereby declares that these proximity readers are in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. Por el presente, HID Global declara que estos lectores de proximidad cumplen con los requisitos esenciales y otras disposiciones relevantes de la Directiva 1999/5/EC. HID Global déclare par la présente que ces lecteurs à proximité sont conformes aux exigences essentielles et aux autres stipulations pertinentes de la Directive 1999/5/CE. A HID Global, por meio deste, declara que estes leitores de proximidade estão em conformidade com as exigências essenciais e outras condições da diretiva 1999/5/EC. HID Global bestätigt hiermit, dass die Leser die wesentlichen Anforderungen und anderen relevanten Bestimmungen der Richtlinie 1999/5/EG erfüllen.
