4-8 Scanner Menu
Freq Scan Menu
Key Sequence: Scanner > Scan Frequencies > Scan Frequencies
Start Freq: Sets the center frequency of the first channel to be displayed.
Freq Scan
Freq Step Size: Sets the spacing between frequencies on the display.
Start Freq
Bandwidth: The channel bandwidth can be manually entered
in GHz, MHz, kHz, or Hz.
580.000 kHz
Number of Channels: Sets the number of channels to be displayed
Freq Step Size
(1 to 20).
10.000 kHz
Back: Returns to the
Bandwidth
9.000 kHz
Number of Channels
20
Back
Figure 4-4. Channel Scanner Frequency Scan Menu
4-8
"Scanner Menu" on page
PN: 10580-00349 Rev. H
www.tehencom.com
Channel Scanner (Option 27)
4-7.
