CDMA Signal Analyzer
PN Setup Menu
Key Sequence: Setup > PN Setup
PN Setup
PN Trigger
No Trig GPS Ext
PN Search Type
Auto Manual
Manual PN Offset
N/A
PN Increment
1
Back
Figure 2-17. CDMA PN Setup Menu
3GPP2 MG
PN Trigger: This submenu key toggles through "No Trig" (no trigger), "GPS",
and "Ext" (external trigger).
PN Search Type: This submenu key toggles between "Auto" and "Manual"
PN search. In the Auto mode, the instrument automatically searches for the
strongest PN. When using manual setup, enter the required PN offset to limit
the search. Auto search is available only when the trigger selection is GPS
or External. If "No Trig" is selected, then pressing this submenu key causes
an error message to be displayed, stating "Applicable only when PN Type is
GPS or External".
Manual PN Offset: Press to manually set the PN offset. Use the arrow keys,
rotary knob, or numeric keypad to choose an offset, then press the rotary
knob or the Enter key to select the value. Editing this value automatically
changes the PN Search Type to Manual.
The Manual PN Offset function is available only when the trigger selection is
GPS or External. If "No Trig" is selected, then pressing this submenu key
causes an error message to be displayed, stating "Applicable only when PN
Type is GPS or External".
PN Increment: Use the arrow keys, rotary knob, or numeric keypad to set
the PN increment value.
Back: Returns to the
PN: 10580-00235 Rev. D
"Setup Menu" on page
www.tehencom.com
2-12 Setup Menu
2-22.
2-23
