TABLE OF CONTENT Warnings ..................... 3 AC403 SETUP REQUIREMENTS ............7 STEP 1 - Charge Parent Unit ............. 8 STEP 2 - Install Sensor Pad ..............10 STEP 3 - Setup Nursery Unit ............. 11 STEP 4 - Turn on your Monitor ............12 STEP 5 - Test and get to know your Monitor ......14...
WARNING 1. THIS PRODUCT CANNOT REPLACE RE- 8. Keep monitor AWAY from heat sources SPONSIBLE ADULT SUPERVISION. This (such as stoves, radiators, etc.). product is designed to aid in the monitoring of your child. When using the monitor, you 9. ALWAYS place both the Nursery Unit and must still provide the supervision necessary Parent Unit on a flat surface in an upright for the continued safety of your child.
Page 4
IMPORTANT SAFETY INSTRUCTIONS or table recommended by the manufacturer or sold with the product. Any mounting of 15.1 Read these instructions - All the safety the product should follow the manufacturer’s instructions should be read before the prod- instructions. uct is operated. 15.11 Unplug this appliance during lightning 15.2 Keep these instructions.
Page 5
Sensor Pad mea- suring at least 13” x 13” (33 x 33 cm) and 1/4 inch (6 mm) thick. Only use your Angelcare ® monitor in a stationary sleeping environment such as a crib where the Sensor Pad can rest on a completely flat, firm surface.
Page 6
16.11 If and when necessary, the batteries WARNING must be replaced with identical new ones or equivalent (volts and size). If a battery to be (North America Only) replaced is connected with other batteries in 17.1 Modifications not authorized by the man series, replace the other batteries at the same ufacturer may void users authority to operate time as well.
Page 7
MOVEMENT & SETUP REQUIREMENTS SOUND MONITOR Model AC403 INCLUDED: 3 Rechargeable AAA 2 AC Adapters (AC403) or Parent Unit(s) Nursery Unit Batteries (AC403) or 3 AC Adapters (AC403-2P 6 Rechargeable AAA Batteries (AC403-2P) Cover 1: Under the mattress Cover 1: Under the mattress...
STEP 1 - CHARGE PARENT UNIT (15 HOURS) IMPORTANT Never use regular alkaline batteries in the Parent Unit; they may explode. 1) Remove the battery cover and insert the Rechargeable Batteries (included). 2) Connect the AC Adapter to the Parent Unit and into an electrical outlet.
Page 9
HOW TO CHARGE THE BATTERIES IN THE PARENT UNIT: Plug the AC into the Parent Unit and a working electrical outlet. Your Parent Unit can function with the batteries at 1/2 capacity but it is recommended that they are fully charged before unplugging from the AC Adaptor and power outlet for maximum use.
STEP 2 - INSTALL SENSOR PAD(S) 1) Place the hardboard in the middle Place the hardboard in the middle of the crib between the base of the crib of the crib between the base of the crib and the mattress. and the mattress.
STEP 3 - SETUP NURSERY UNIT 1) Remove the battery cover and insert 4 AAA Alkaline Batteries (not included). 2) Place the Nursery Unit at a minimum of 1m (3ft) away from the crib. 3) Connect the AC Adapter to the Nursery Unit and plug into an electrical outlet.
STEP 4 - TURN ON YOUR MONITOR 1) Press the Parent Unit ON/OFF button for 2 seconds. 2) Slide ON the Nursery Unit Power ON/OFF button. NOTE: The screen of the Parent Unit will show the channel of transmission (C1 to C8) and after 5 seconds the room temperature and function icons.
Page 13
IMPORTANT ICONS SOUND TRANSMISSION (VOX) Detection Mode Icons: Indicates selected dectection mode: Nursery Unit: Movement Only Appears when options are being set for the Nusery Unit Sound only Out-of-Range: Indicates the loss of connection ‘TIC’, Sound & Movement between the Parent Unit and Nursery Unit.
STEP 5 - TEST AND GET TO KNOW YOUR MONITOR ® The Angelcare monitor can be used with the pre-program factory settings or you can also customize your settings to your preference. All changes and adjustments made in the main menu and sub-menu will...
Page 15
5.3 - CHANGING THE MOVEMENT AND SOUND MONITORING FUNCTIONS TO SET DETECTION MODE: 1) Press the MENU button once and the flashing icons will appear. 2) Use the UP and DOWN Arrows to select your preferred detection mode. 3) Press the SELECT button to confirm your choice.
Page 16
TO STOP THE ALARM Shut the Nursery Place your hand Press Unit OFF back on the any key mattress. to put on Hold (see section 6.6) TO ADJUST THE SENSOR PAD SENSITIVITY LEVEL: You can adjust the Nursery Unit sensitivity dial to change your Sensor Pad from less sensitive to very sensitive.
Page 17
TO ACTIVATE THIS FUNCTION: 1) Press MENU button 2 times. The Out-of-Range Indicator will blinks. 2) Using the UP and DOWN Arrows, turn the function ON or OFF. 3) Press the SELECT button and then EXIT to confirm your choice. OUT-OF-RANGE ALARM The Out-of range Icon will also flash •...
Page 18
VOICE ACTIVATION (VOX) OR CONTINOUS SOUND MODE VOICE ACTIVATION (VOX) OR CONTINOUS SOUND MODE Allows you to select your option on how you monitor sound: Allows you to select your option on how you monitor sound: VOX (voice activation picks up sound based on the setting of the sensitivity level) or VOX ( ( voice activation picks up sound based on the setting of the sensitivity level) or Continuous (sound monitoring is continuously on, picking up all sounds).
Page 19
ADJUST THE SOUND LEVEL PUT IN TEMPORARY MUTE MODE Press the SOUND/OFF button once to mute the sound (see section 6.4). Raise volume Lower volume 5.6 - TEMPORARY MUTE Allows you to put your monitor in temporary MUTE mode. TO ACTIVATE MUTE: Press the SOUND/OFF button.
Page 20
Parent Unit or the Nursery Unit even if they were activated before pressing the MENU or SUB-MENU mode. 5.8 - HOLD Allows you to put your Angelcare monitor on HOLD. 1) Press and hold the Down Volume arrow for 2 seconds.
Page 21
5.9 - TEMPERATURE TO ACTIVATE THE TEMPERATURE ALARM: 1) Press the MENU button 6 times. The Temperature Indicator (Low and High) will appear. 2) Using the arrows, to turn the function ON or OFF. 3) Press SELECT button to confirm your choice.
Page 22
YOU ARE NOW READY TO USE YOUR MONITOR The Angelcare ® monitor can be used with the pre-program factory settings or you can also customize your settings to your preference. DEFAULT SETTINGS Detection Mode: Sound & Movement Temperature Unit: Celsius...
STEP 6 – ACTIVATE AND DEACTIVATE ADDITIONAL FUNCTIONS The Angelcare ® monitor can be used with the pre-program factory settings or you can also customize your settings to your preference. All changes and IMPORTANT adjustments made in the When in MENU or SUB-MENU mode...
TROUBLESHOOTING TAKING CARE OF YOUR RECHARGEABLE BATTERIES • Ensure that you fully charge your batteries for 15hrs before their first use. • To maintain maximum battery life it is recommended that you fully discharge your batteries periodically. Battery performance can be diminished by leaving the batteries constantly charging.
Page 25
FALSE ALARMS • Verify the connection between Sensor Pad and Nursery Unit. Unplug and reconnect the cord. • Make sure there is no bedding between the mattress and the Sensor Pad. • If the crib has a spring or slat base, place a hardboard between the crib base and the Sensor Pad measuring at least 13”...
® rechargeable, movement and sound monitor (model AC403) is free from any material and workmanship defects, for a period of one (1) year (rechargeable batteries not included) from the date of the original purchase. If this monitoring system fails to function properly when used as ®...
This electronic equipment contains reusable material and must not be disposed with domestic waste. Please take it to a collecting point for electric and electronic equipment (ask your local authorities for details). ErP COMPLIANCE SOUTH AFRICA-BRAZIL-ECUADOR-EUROPEAN UNION Use only Angelcare ® Brand power supply-model number T07505V001 GERMANY ®...
