Page 2: Table Of Contents
High-Capacity Ink Pack Adapter OPERATION MANUAL Table of Contents 1 Introduction ········································································· 3 1.1 Purpose of This Manual and Its Target Readers ·································· 3 1.2 Safety Instruction ··········································································· 3 1.3 Warning label ················································································· 4 1.3.1 Precautions on handling the warning label ················································· 4 1.3.2 Warning label location and type ································································... -
Page 3: Introduction
The product and the information contained herein are subject to change without notice. MUTOH has made the best efforts to keep this document free from error, but if you find any uncertainties or misprints, please call us or the shop where you purchased this product. -
Page 4: Warning Label
To remove dirt from the warning label, please use a cloth, water, and mild detergent. Do not use organic solvents or gasoline to clean the label. It is necessary to replace the label if damaged, lost or illegible. If the warning label needs to be replaced, contact to your local MUTOH dealer. -
Page 5: Warning Label Location And Type
High-Capacity Ink Pack Adapter OPERATION MANUAL 1.3.2 Warning label location and type The diagram below indicates the location of the warning label. Type of warning label... -
Page 6: Checking The Contents
After unpacking the packing box, check that the printer is not damaged and all necessary parts are included. After checking, if the printer is damaged or some parts are missing, contact your local MUTOH dealer. 2.1 Contents in the Box <VJ-HCIPADPT-UV6>... -
Page 7: Assembling The Light-Shielding Cases
High-Capacity Ink Pack Adapter OPERATION MANUAL 2.2 Assembling the Light-shielding Cases 1. Check the outer and the inner sides of the light-shielding case. ・ The rough surface with double-sided tape on it is the outer side of the light-shielding case. Part Name Light-shielding case (outer side) Double-sided tape... - Page 8 High-Capacity Ink Pack Adapter OPERATION MANUAL 3. Peel off the cover on the double-sided tape, and connect the light-shielding case. Part Name Double-sided tape 4. Fold in the upper side of the light-shielding case. 5. Assemble the rest of the light-shielding cases in the same way.
-
Page 9: How To Use
High-Capacity Ink Pack Adapter OPERATION MANUAL 3 How to Use This section describes how to use this product. Be sure to read the “Notification sheet (UVE-H-00)” included with the printer before operating it. 3.1 Installing Ink Bags Follow the procedure below to install the ink bags. 1. - Page 10 High-Capacity Ink Pack Adapter OPERATION MANUAL 4. Make sure that smart chip card is fully inserted in place so that the card does not cover the top tabs. Part Name Smart chip card Top tabs 5. Attach ink color labels to high-capacity ink pack adapters as shown in the illustration below. ・Use "spare"...
- Page 11 High-Capacity Ink Pack Adapter OPERATION MANUAL 6. While lowering the lock lever of the high-capacity ink pack adapter, insert an ink bag. Make sure to fully insert the ink bag into the high-capacity ink pack adapter. Part Name High-capacity ink pack adapter Lock lever Ink bag Confirm ink bag is fully seated by checking the lock mechanism is at the top of the ink delivery...
- Page 12 High-Capacity Ink Pack Adapter OPERATION MANUAL 7. Make sure that the lock lever of the high-capacity ink pack adapter is back to its original position. Part Name High-capacity ink pack adapter Lock lever After inserting an Ink bag to the high-capacity ink pack adapter, if the lock lever does not return to its original position, push up the lever with your finger.
- Page 13 High-Capacity Ink Pack Adapter OPERATION MANUAL 8. Place the light-shielding cover over the ink bag. Insert the light-shielding cover inside the high-capacity ink pack adapter to only cover the ink bag. Part Name Light-shielding cover High-capacity ink pack adapter If the light-shielding cover is not inserted firmly inside the high-capacity ink pack adapter, the ink in the bag may be transformed and the printer may get damaged.
- Page 14 High-Capacity Ink Pack Adapter OPERATION MANUAL Check if the color name on the ink bag can be seen from the confirmation window in the light-shielding cover. ・ Also check that the ink color label you attached in Step 5 matches the color name on the ink bag.
-
Page 15: When High-Capacity Ink Pack Adapter Is Removed From Printer
High-Capacity Ink Pack Adapter OPERATION MANUAL 3.2 When High-Capacity Ink Pack Adapter is removed from Printer When the high-capacity ink pack adapter is removed from printer, follow the procedures below to wipe off the ink. Make sure to wipe off the ink adhering to the ink pack adapter when removing from the printer. - Page 16 High-Capacity Ink Pack Adapter OPERATION MANUAL (2) Operation Procedures 1. Wear plastic gloves, rubber gloves, goggles and protective clothing. Refer to the Operation Manual of the printer for how to wear. 2. Check if the printer is turned on. 3. Remove the high-capacity ink pack adapter from the printer. 4.
- Page 17 High-Capacity Ink Pack Adapter OPERATION MANUAL 5. Tilt the high-capacity ink pack adapter as shown in the figure below to absorb ink using the cleaning stick supplied with the printer (or commercially available tissue with sharp-edged). ・ Tilt the high-capacity ink pack adapter so that the inlet to be pointed downward a little. ・...
-
Page 18: Replacing Adapter's Plug
High-Capacity Ink Pack Adapter OPERATION MANUAL 3.3 Replacing Adapter’s Plug (1) When to replace When “[*******] Change Plug” is displayed on the Operation panel; ・ Adapter’s plug of high-capacity ink pack adapter needs to be replaced. ・ Warning buzzer beeps. To stop the buzzer, press the [Enter] key on the operation panel. - Page 19 (Commercially available tissue can be used as an alternative to paper towel.) ・ High capacity ink pack adapter (UV) sealing jig (hereinafter called “sealing jig”) When the included adapter’s plugs have run out, contact your local MUTOH dealer. ...
- Page 20 High-Capacity Ink Pack Adapter OPERATION MANUAL (3) How to replace Do not replace the Adapter’s plug in a place with direct sunlight or strong light. Ink may cure by ultraviolet light and it may cause printer damage. Follow the procedure below to replace Adapter’s plug. 1.
- Page 21 High-Capacity Ink Pack Adapter OPERATION MANUAL 7. Remove the smart chip card from the high-capacity pack adapter. Part Name Smart chip card High-capacity ink pack adapter Tabs Once removed, keep the ink bag and the smart chip card together in the same place. 8.
- Page 22 High-Capacity Ink Pack Adapter OPERATION MANUAL 9. While lowering the lock lever of high-capacity ink pack adapter, insert the sealing jig. Make sure to insert the sealing jig all the way in the high-capacity ink pack adapter. Part Name High-capacity ink pack adapter Lock lever Sealing jig Confirm the sealing jig is fully seated by checking the lock mechanism is at the top of the ink...
- Page 23 High-Capacity Ink Pack Adapter OPERATION MANUAL 10. Use a fine-tipped tool to push out the tube connector from the left gap of the high-capacity ink pack adapter. When replacing the adapter’s plug, make sure that the sealing jig is properly inserted to the adapter. If not inserted, ink remained in the tube may spill out from the connector.
- Page 24 High-Capacity Ink Pack Adapter OPERATION MANUAL 12. Use a fine-tipped tool to remove the adapter’s plug from the tube connector. Do not bend the tube connected to the tube connector as much as possible. The tube may be broken. ...
- Page 25 High-Capacity Ink Pack Adapter OPERATION MANUAL 13. Push a new adapter’s plug into the tube connector about a half way. Push the adapter’s plug into the tube connector completely. (If difficult, push while turning the adapter’s plug with one finger to fully insert it into the connector.) Part Name Adapter’s plug...
- Page 26 High-Capacity Ink Pack Adapter OPERATION MANUAL 14. Install the tube connector back to the tabs of high-capacity ink pack adapter securely. Part Name Tube connector Tabs High-capacity ink pack adapter If the tube connector is not securely installed to the tabs, the high-capacity ink pack adapter may not be installed to the printer correctly.
- Page 27 High-Capacity Ink Pack Adapter OPERATION MANUAL 16. Wipe off the ink adhering around the inlet of the sealing jig using the paper towel supplied with the printer (or commercially available tissue). Part Name Inlet Paper towel After using the sealing jig, always keep it in the aluminum foil bag. If not, ink around the jig may get dry and the jig may not be usable again.
