LCD Display Test

Use this test to assess the performance of the
LCD.
To test the LCD:
Press F1 Utility, if necessary, to enter Utility
1
mode.
Select Disp (Display) by pressing the channel
2
4 Select switch.
Press channel 1 Select to start the LCD test. All
3
pixels in the LCD light solid, letting you quickly
tell if any area of the display is damaged.
To turn to all black, press channel 3 Select.
4
To exit Display Test mode, press channel 8 Se-
5
lect (Exit).
To exit Utility mode, press F1 Utility.
6

Switch Test

Use this test to evaluate the performance of
Command|8 switches.
To test switches:
Press F1 Utility, if necessary, to enter Utility
1
mode.
Select the Switch test by pressing the channel
2
5Select switch.
Press any Command|8 switch to test it. The
3
LCD displays the location and name of each
switch as you test it.
To exit Switch test mode, press channel 8 Se-
4
lect (Exit).
To exit Utility mode, press F1 Utilityl.
5

Encoder Test

Use this test to evaulate the performance of the
Command|8 rotary encoders.
To test the encoders:
Press F1 Utility, if necessary, to enter Utility
1
mode.
Select Encodr (Encoder) by pressing the chan-
2
nel 6 Select switch.
Rotate any encoder to test it. Encoder value is
3
displayed in the LCD while testing.
To exit Encoder test mode, press channel 8 Se-
4
lect (Exit).
To exit Utility mode, press F1 Utility.
5
Appendix A: Utility Functions 57
