LED Tests

Use this test to check all LEDs of similar color si-
multaneously.
To test LEDs:
Press the F1 Utility switch to enter Utility
1
mode.
Press the Channel Select switch that corre-
2
sponds to LED.
The LCD displays tests for each LED color:
Grn (green), Red, Yel (yellow), and All.
Select a test by pressing its corresponding
3
Channel Select switch. To test all LEDs simulta-
neously, select All. The selected LEDs light solid.
To turn off the LEDs, select Off.
4
Press the Channel Select switch that corre-
5
sponds to Exit.
Press the F1 Utility switch to exit Utility mode.
6

LCD Display Test

Use this test to assess the performance of the
LCD display.
To test the LCD display:
Press the F1 Utility switch to enter Utility
1
mode.
Press the Channel Select switch that corre-
2
sponds to Disp.
Do one of the following:
3
• Press the Channel Select switch that corre-
sponds to Block to light all LCD pixels.
– or –
• Press the Channel Select switch that corre-
sponds to Off to extinguish all LCD pixels.
Press the Select switch on Channel 8 to stop
4
the test.
Press the Channel Select switch that corre-
5
sponds to Exit.
Press the F1 Utility switch to exit Utility mode.
6
