Sends - DigiDesign Command 8 Manual

Press F3 PRE/MIDI Recall. The LCD displays
3
PRE unit number, channel number, and gain
value in the LCD above each audio track. Be-
cause multiple PREs can be in use, unit and
channel number are indicated as follows.
PRE unit number (top row) per channel (lower row) as
displayed in the LCD
1/1 10 1/2 21
(ch 1) (ch2)
• The first two numbers per channel indicate
unit and channel number. Above, "1/1" in-
dicates PRE unit #1, channel 1; "1/2" indi-
cates unit #1, channel 2). If using two
units, their channels (when banked) would
be listed as "2/1", "2/2" and so on.
• The two digit gain value for that unit and
channel (PRE gain ranges from 0–69).
Rotate the encoder below the desired unit and
4
channel shown to adjust PRE gain on that chan-
nel.
Bank left or right to bank other PRE tracks to
5
the channel strips.

Sends

Command|8 lets you adjust Pro Tools send
level, pan, pre/post fader tap, and send mute.
(You cannot assign or remove sends from Com-
mand|8; use Pro Tools onscreen controls and
the mouse instead.)
Sends can displayed and accessed in either Con-
sole or Channel View modes.
The F5 Focus switch toggles between the
current and previous Console or Channel
view. See "Function/Utility Switches" on
page 28.
38 Command|8 Guide
1/3 54 cont.
(ch3) (chs4–8)
To view and adjust send levels for all currently
banked tracks (Console View):
Press the Send switch to the left of the rotary
1
encoders to enter Send view.
Select a send (A–E) by pressing the corre-
2
sponding switch from among the Send A–E
switches at the far left of the control surface. The
LCD displays the status of the selected send
(A–E) of each currently banked track (whether
assigned to a bus, output, or none).
A–E
To view and adjust sends on a single track
(Channel View):
Press the Pan/Send switch in the Channel
1
View switch section.
Press a channel Select switch. The correspond-
2
ing track Name appears in the LCDs upper row,
Pan in the first channel of the lower row, and
the five sends for the track are listed across chan-
nels 3–7. This means that Send A for the selected
track is shown in channel 3, Send B in channel
4, and so on. The send assignment is shown
above each channel (bus 1-2, output 3-4, and
similar).
Use the rotary encoders to adjust send levels.
3
To check the selected track name, press and
hold Display Mode. Release to return to the
previous view.
Send
