Kontron KBox M-100 Quick Installation Manual

KBox M-100 - QUICK INSTALLATION GUIDE
Thank you for purchasing the Kontron KBox M-100 fanless box PC. This document provides information to allow you to quickly
install this product.

Packing Checklist

1. Take the KBox M-100 out of the packing box and check if the unit is properly secure in the plastic bag.
2. Check the contents of the carton box: (*: optional)

1x KBox M-100

1x Power Adapter

1x Power Cord*

Memory Module(s)* (It may be pre-installed in the system depending on ordered configuration.)

mSATA SSD* (It may be pre-installed in the system depending on ordered configuration.)

Wall Mounting Kit*

Front I/O Panel

2
1 Power Switch
2 Power LED
3 HDD LED
4 USB 2.0
5 RS232
6 Parallel Port
KBox M-100 - Quick Installation Guide - Version 1.0
1 4
3
www.kontron.com
//
6 5
5
5
5
// 1
