Summary of Contents for Origin Acoustics DBA10
- Page 1 DBA10 In-Ceiling Subwoofer DBA10 Installation Manual...
-
Page 2: Table Of Contents
DBA10 In-ceiling Subwoofer Manual Table of Contents Introduction Specifications What’s Included Tools & Items Wire Recommendation Subwoofer Placement About Speaker Wire Installing the Wire Wire Routing For New Construction Painting the Grille Cutting the Hole Installing the Bayonet Ring Connecting the Wire... -
Page 3: Introduction
Introduction Thank you for purchasing the DBA10 in-ceiling Subwoofer. At Origin Acoustics, we take pride in providing you with a high quality product. All of Origin Acoustics’ speakers are designed to have excellent sound quality, longevity, and a simple installation process. -
Page 4: Specifications
DBA10 In-ceiling Subwoofer Manual Specifications • Woofer: 10” Fiberglass • Power Handling: 50-175 Watts • Diameter: 11 ” (286mm) • Grille Diameter: 11 21/ 3 2” (296mm) 1/ 4 • Grille Diameter: 11 21/ 3 2” (296mm) • Cutout Diameter: 10 3/ 8 ” (264mm) •... -
Page 5: What's Included
DBA10 In-ceiling Subwoofer Manual 11.75in 298.6mm 5.55in What’s Included 140.9mm Speaker Bayonet Ring Grille Template DBA10 SCALE:1:4 Tools & Items • Drywall Saw • Measuring Tape • Stud Finder • Speaker Wire • Drill • Fish Tape • Pencil •... -
Page 6: Subwoofer Placement
DBA10 In-ceiling Subwoofer Manual Subwoofer Placement The music we hear as bass is made up of frequencies that have long to very long wavelengths (6ft. to 50ft.). Therefore, when a subwoofer is placed into a room, its position in the room will affect the amount of bass perceived by the listener. In other words, placing the speaker in some areas of a room will result in more bass than in other areas of the same room. -
Page 7: About Speaker Wire
DBA10 In-ceiling Subwoofer Manual About Speaker Wire You will need a wire that has at least two conductors; one that can be identified as the positive and the other as the negative. All two conductor wires have some means of identifying which conductor is which, but at times this identification may be subtle. -
Page 8: Wire Routing
DBA10 In-ceiling Subwoofer Manual 2. Wire Routing Plan how you’ll route the wire to the desired speaker location. There are several methods for routing the wire, and you may need to combine several of them. Behind the Baseboard Through Walls... -
Page 9: Painting The Grille
DBA10 In-ceiling Subwoofer Manual 4. Painting the Grille In some situations the speakers may look better if the color matched the walls, ceiling, or trim in the room. This can be accomplished by painting the grille. The grille must be painted with spray paint, and most hardware stores will mix a can of paint to match whatever color you need. -
Page 10: Installing The Bayonet Ring
DBA10 In-ceiling Subwoofer Manual template, check the Specifications section for cutout sizes.) If you’re unsure on whether there may be obstacles (such as pipes or wires) where you plan on installing the speaker, drill a ⅛ inch hole in the center of the circle, then put a bent coat hanger through the hole to feel around. -
Page 11: Connecting The Wire
DBA10 In-ceiling Subwoofer Manual 7. Connecting the Wire Insert the wires into the connectors, making sure that the positive wire is being attached to the red connection and the negative wire is being Connector attached to the black connection. If... -
Page 12: Subwoofer/Amplifier Setup
For the highest quality performance, Origin Acoustics has two amplifiers that are specifically designed to drive the DBA10 as well as other in-wall and in-ceiling subwoofers in the Origin line. The SUBA150 is a dedicated, single-channel subwoofer amplifier with both line level and speaker level inputs. -
Page 13: Troubleshooting
DBA10 In-ceiling Subwoofer Manual Troubleshooting If possible, it’s often good to try to isolate the problem first. For example, if you’re playing a DVD on a television and there’s no sound, try connecting an MP3 player to the system to see if that works. If it does work, then the problem is with the tele- vision, DVD player, or the cables connecting them. -
Page 14: Technical Assistance
If you are considering returning the product, it’s required that you contact Origin Acoustics prior to any return attempts. This way we can determine if the issue can be resolved without returning the product, or if needed we can provide instructions and support for the return process. -
Page 15: Warranty
If the product is determined to be defective, it will be repaired or replaced at Origin Acoustics’ discretion. If the product must be replaced yet it is no longer manufactured, it will be replaced with a model of equal to or greater value that is the most similar to the original. -
Page 16: Return Process
Before making any return attempts, it is required that you first contact Origin Acoustics. Return product to Origin Acoustics or your dealer, either in person or by mail. It’s preferable if the product is returned in the original packaging. If this isn’t possible, the customer is responsible for insuring the shipment for the full value of the product. - Page 17 6975 S Decatur Blvd, Las Vegas, NV 89118 • www.originacoustics.com • 844-674-4461 ©2018 Origin Acoustics. All copyrighted, trademarked and patented elements mentioned herein are the sole property of Origin Acoustics.
