Origin Acoustics DIRECTOR COLLECTION DSUB6X2 Quick Start Manual

DIRECTOR COLLECTION
DSUB6X2 IN-CEILING SUBWOOFER
PAIRS WITH 5", 6" & 8" DIRECTOR SERIES SPEAKER GRILLES
6.97in
SPECIFICATION
177.00mm
System Type
Driver Components
Crossover
Frequency Response
14.02in
356.00mm
Maximum SPL @ 1m
Sensitivity (2.83V/1m)
Power Handling
Recommended Amp Power
Rated Impedance
Input Connectors
Enclosure
Mounting
DSUB6x2
SCALE:1:10
Please visit docs.originacoustics.com or scan this QR code using your smart device for the
most up to date safety information and use instructions for this product.
*All warranties and warranty conditions are subject to change. Please
refer to docs.originacoustics.com for the latest information.
TM
DSUB6X2
Three Chamber Bandpass Vibration Canceling,
In-Ceiling Subwoofer
Two 6.5'' Poly Cone Subwoofers
Recommended LPF 150Hz or less
24 dB BW
32Hz - 180Hz [ - 10 dB]
40Hz - 150Hz [ +/- 3 dB]
111 dB Continuous, 114 dB Peak
90 dB
60W Pink Noise / 120W Program / 240W Peak
50 - 250 Watts (FCT) @ 4Ω
6Ω
Gold Plated Spring Push Terminals
MDF
Overlapping Formed Steel Straps,
Adjustable from 14.5''– 22.5''
MODEL DSUB6X2
PART DSUB6X200
Height 7'' (177 mm)
Width 14'' (356 mm)
Length 22'' (559 mm)
Weight 29.5lbs (13.4kg)
