User guide – Holiday calendar
HOW TO CONFIGURE THE HOLIDAY CALENDAR?
①
Press on the Holiday calendar button.
HOLIDAY CALENDAR
It lets you define on your
calendar which days are
holidays.
It allows you to define different
sendings depending on whether
it is holiday or workday.
www.zennio.com
- 1 -
Z41 Pro/Lite/COM

Advertisement

loading
Need help?

Need help?

Do you have a question about the Z41 Pro and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Zennio Z41 Pro

Summary of Contents for Zennio Z41 Pro

  • Page 1 Press on the Holiday calendar button. HOLIDAY CALENDAR It lets you define on your calendar which days are holidays. It allows you to define different sendings depending on whether it is holiday or workday. www.zennio.com - 1 - Z41 Pro/Lite/COM...
  • Page 2 It will not be marked in orange then. By sliding across the days while holding pressed, it is possible to select several days in a quicker way. Close the pop-up window. www.zennio.com - 2 - Z41 Pro/Lite/COM...
  • Page 3 Run / Stop It is a control that lets configure and execute a set of sequential actions. Settings These actions are selected among those already configured for the different boxes of the touch panel. www.zennio.com - 3 - Z41 Pro/Lite/COM...
  • Page 4 User guide – Macro ② Add a new action Up to 10 actions per macro can be configured. Add action Close the pop-up window www.zennio.com - 4 - Z41 Pro/Lite/COM...
  • Page 5 With delay of 0 s the actions will be executed simultaneously. Delete. With a long press Move among the actions. on the selected action, it will be removed. www.zennio.com - 5 - Z41 Pro/Lite/COM...
  • Page 6 Interval of 5 seconds between them: 1. Mirror light → ON 2. Bathroom light → ON 3. Bathroom light → OFF 4. Living room. LEDs → Green In this example, the Macro will take 19 seconds to be completed. www.zennio.com - 6 - Z41 Pro/Lite/COM...
  • Page 7 When disabled, the icon will appear between both These actions selected buttons. among those already configured for the different boxes of the touch panel, and can be defined depending on the day type (working/holiday). www.zennio.com - 7 - Z41 Pro/Lite/COM...
  • Page 8 Note: It is not possible to set time-controlled actions for boxes either configured as indicator or of the type “Other”, except for Macros, Logical functions and RGB(W) control. Close the pop-up Add action. window www.zennio.com - 8 - Z41 Pro/Lite/COM...
  • Page 9 Boxes already configured in the Controls already configured for page that has been chosen. that box. Delete. With a long press on the Move among the actions. selected action, it will be removed. www.zennio.com - 9 - Z41 Pro/Lite/COM...
  • Page 10 Let’s imagine that we want to program a time-controlled action so that at 18:10 on Saturdays and Sundays of my holiday calendar, a setpoint of 26,5 ºC for the air conditioning in the living room is set. The settings will be as follows: www.zennio.com - 10 - Z41 Pro/Lite/COM...

  • Page 11: Logical Function

    The actions that are executed, as well as the conditions for the execution of the function, are actions already configured in the other boxes of the touch panel. www.zennio.com - 11 - Z41 Pro/Lite/COM...
  • Page 12 User guide – Logical function ② Add a new operation Up to 3 operations per logical function can be configured. Add operation Close the pop-up window www.zennio.com - 12 - Z41 Pro/Lite/COM...
  • Page 13 Page, Box and Value of the selected item (either for selecting the restrictions or the actions). Delete. With a long press on the selected action, it will be removed. www.zennio.com - 13 - Z41 Pro/Lite/COM...
  • Page 14 Page, Box and Value will be restriction is fulfilled). chosen at the bottom (so that both restrictions are section. met). The name of the box and its value will be updated in the upper section. www.zennio.com - 14 - Z41 Pro/Lite/COM...
  • Page 15 Page, Box and Value will The box will be highlighted in be chosen at the bottom orange colour. section. The name of the box and its value will be updated in the central section. www.zennio.com - 15 - Z41 Pro/Lite/COM...
