Enclosure Dimensions - Altronix T2428300E Installation Instructions

1.25"
(31.75mm)
1.5"
(12.7mm)
3.5"
(88.9mm)
12"
(304.8mm)
2.5"
(63.5mm)
3.5"
(88.9mm)
1"
(25.4mm)
4.5"
(114.3mm)
Altronix is not responsible for any typographical errors. Product specifications are subject to change without notice.
140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056
website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty | Made in U.S.A.
IIT2428300E - Rev. 040705

Enclosure Dimensions:

12.25" x 7.25" x 4.5" (311.15mm x 184.15mm x 114.3mm)
