- Page 1 Manual No: 576013-763 ● Revision: K Groundwater Sensor Installation Guide...
- Page 2 Customer Service will work with production facility to have the replacement product shipped as soon as possible. If “lost” equipment is delivered at a later date and is not needed, Veeder-Root will allow a Return to Stock without a restocking fee.
-
Page 3: Table Of Contents
Table of Contents Introduction Contractor Certification Requirements ................1 Product Marking Information .....................1 Related Documents ....................1 Safety Warnings .......................3 Safety Symbols .........................3 Installation Components ...................4 Sensor Installation ......................5 Figures Figure 1. Installation Kit ..................4 Figure 2. Groundwater Sensor Installation ............5 Figure 3. Epoxy Sealing Field Wiring Connections ..........6... -
Page 4: Contractor Certification Requirements
RELATED DOCUMENTS Documents Required to Install Equipment This intrinsically safe apparatus is only for use as part of a Veeder-Root Automatic Tank Gauging System (ATG Console with probes and sensors). To install intrinsically safe apparatus, use the specific control drawing that... - Page 5 Introduction Product Marking Information Non-Hazardous Location CLASS I Division 1, Group D CLASS 1, Zone 0 Associated Apparatus 8470/TLS-350; Hazardous Location Intrinsically Safe Apparatus 8482/TLS-350R ATG Console (F) Red (+) I.S. Sensor (G) Green (-) Groundwater Connections Sensor (W) White (+) Non-Hazardous Location Associated Apparatus 8601/TLS4 Console...
-
Page 6: Safety Warnings
Introduction Safety Warnings Safety Warnings To protect yourself and your equipment, observe the following warnings and important information: WARNING This product is to be installed and operated in the highly combustible environment of a gasoline storage tank where flammable liquids and explosive vapors may be present. FAILURE TO COMPLY WITH THE FOLLOWING WARNINGS AND SAFETY PRECAUTIONS COULD CAUSE DAMAGE TO PROPERTY, ENVIRONMENT, RESULTING IN SERIOUS INJURY OR DEATH. -
Page 7: Installation Components
Introduction Safety Symbols GLOVES USE SAFETY BARRICADES Wear gloves to protect hands from irritation or Unauthorized people or vehicles in the work area are injury. dangerous. Always use safety cones or barricades, safety tape, and your vehicle to block the work area. WEAR EYE PROTECTION INJURY Fuel spray from residual pressure in the lines... -
Page 8: Sensor Installation
Sensor Installation 1. Turn off AC power to the Veeder-Root monitoring system. 2. Remove any existing cap from the well in which the sensor will be installed. (A new well cap is supplied with the groundwater sensor.) 3. Lower the groundwater sensor into the monitoring well until the water float touches the bottom of the well. -
Page 9: Figure 3. Epoxy Sealing Field Wiring Connections
Sensor Installation Safety Symbols 6. Press the sensor well cap into the top of the well with the excess sensor length hanging inside the well housing. Press down the locking handle on the sensor well cap to secure it in position and to form a water-tight seal between the sensor well cap and the monitoring well housing. - Page 10 For technical support, sales or other assistance, please visit: www.veeder.com...
