- Page 1 • Manual No: 577013-801 Revision: A P r e s s u r e M a n a g e m e n t C o n t r o l Install, Setup, & Operation Manual Section 16 Pressure Management Control 16-i...
- Page 2 Notice Veeder-Root makes no warranty of any kind with regard to this publication, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. Veeder-Root shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this publication.
- Page 3 Warranty Registration and Checkout Form has been filed with Veeder-Root by an authorized Veeder-Root Distributor. This warranty will not apply to any product which has been subjected to misuse, negligence, accidents, systems that are misapplied or are not installed per Veeder-Root specifications, modified or repaired by unauthorized persons, or damage related to acts of God.
-
Page 4: Table Of Contents
Table of Contents Introduction Site Requirements ......................1 Contractor Certification Requirements ................1 Related Manuals .......................2 Safety Precautions ......................2 Installation Vapor Pressure Sensor ....................3 Installing TLS Console Modules - General Notes .............3 Circuit Directory ......................4 Smart Sensor Interface Module ..................4 NVMEM203 Board ......................4 Mod Bus Module .......................4 Setup Introduction ........................5... -
Page 5: Site Requirements
• An RS-232 Port will be available for use by contractor or government inspectors. Contractor Certification Requirements Veeder-Root requires the following minimum training certifications for contractors who will install and setup the equipment discussed in this manual: Level 1... -
Page 6: Related Manuals
Introduction Related Manuals Related Manuals The manuals in Table 1 below are shipped with the equipment on the V-R Tech Docs CD-ROM and will be needed to install specific equipment. Table 1 Related Manuals V-R Manual Part Number TLS-3XX Site Prep Manual 576013-879 Vapor Pressure Sensor Installation Guide 577013-797... -
Page 7: Installation
• Mod Bus Module All field wiring, its type, its length, etc., used for TLS console sensors must conform to the requirements outlined in the Veeder-Root TLS-3XX Site Prep manual (P/N 576013-879). Vapor Pressure Sensor Install one Vapor Pressure Sensor in the vapor return piping of the gasoline dispenser closest to the tanks following the instructions in the Vapor Pressure Sensor Installation guide (P/N 577013-797). -
Page 8: Circuit Directory
Installation Smart Sensor Interface Module CAUTION! During programming, module positions and the devices wired to each module are identified and stored in memory. If a connector is removed and reinstalled on a different module after programming, or if an entire module with its connector is removed and reinstalled in a different module slot, the TLS console will not identify correctly the data being received. -
Page 9: Setup
Setup Introduction This section describes how to perform PMC setup using the TLS console’s front panel buttons and display. The procedures in this manual follow standard TLS console setup programming input, i.e., keypad/display interaction. If necessary, refer to Section 2 of the TLS-3XX System Setup manual (P/N 576013-623) to review entering data via the front panel keypads. -
Page 10: Pmc Setup
Setup PMC Setup PMC Setup Figure 3 diagrams the PMC setup programming. SETUP MODE PRESS <FUNCTION> TO CONT PMC SETUP ---------------------- PMC VERSION: 01.00 PMC SETUP PRESS <STEP> TO CONTINUE VAPOR PROCESSOR TYPE VST VAPOR PROCESSOR MAX RUNTIME MINUTES: 90 ON: -0.200 INCHES VAPOR PROCESSOR Prints out a copy of the... -
Page 11: Operation
Operation Alarms OVERVIEW OF TLS CONSOLE INTERFACE The TLS console is continuously monitoring the vapor recovery system and PMC sensors for alarm conditions. During normal operation when the TLS console and monitored PMC equipment is functioning properly and no alarm conditions exist, the "ALL FUNCTIONS NORMAL" message will appear in the system status (bottom) line of the console display, and the green Power light will be On (see Figure 4). -
Page 12: Warning Posting
Operation Alarms WARNING POSTING Displayed messages alert you to the type of warning. Printed messages show the type of warning and the time the warning was posted (see Figure 5). Warnings are logged into the Non-Priority Alarm History in the TLS. MMM DD, YYYY HH:MM XM TLS console display message... -
Page 13: Pmc Alarm Summary
Operation PMC Alarm Summary PMC Alarm Summary Table 2 contains a listing of the PMC generated alarms including their displayed message and cause. TLS Console PMC alarms may be interspersed amongst non-PMC alarms, please see TLS350 Series manuals for more information. Table 2. -
Page 14: Pmc Status Report
Operation PMC Status Report PMC Status Report MMM:DD, YYYY HH:MM:SS XM ALL FUNCTIONS NORMAL PMC STATUS ---------------------- PMC VERSION: 01.00 PMC STATUS Prints out a copy of the PMC Status report. PRESS <STEP> TO CONTINUE VP OVER PRESSURE TEST See example at right. STATUS: 0.4”WC PASS PMC VERSION 01.00 EFFLUENT EMISSIONS TEST... -
Page 15: Connecting Laptop To Console
Operation Viewing PMC Reports Via RS-232 Connection ALARM WARNING POWER TLS Console TLS-350R TLS-350R RS-232 board (DB25 female) (Slots 1, 2, or 3) Multiport board (DB9 female) DB25 (Slot 4) male male ATEN USB to DB9 serial adapter** P/N 576040-170... -
Page 16: Figure 9. Connection Description Window
Operation Viewing PMC Reports Via RS-232 Connection 2. After opening the terminal software program, ignore (cancel) any modem/dialing related request windows since you will be directly connecting to the console via serial communications. When the Connection Description window appears (Figure 9), enter a connection name, e.g., TLSDIRECT, and click the OK button Figure 9. -
Page 17: Figure 11. Console Comm Port Settings Printout Example
Operation Viewing PMC Reports Via RS-232 Connection a. Go to the console front panel press the MODE key until you see: SETUP MODE PRESS <FUNCTION> TO CONT b. Press the FUNCTION key until you see the message: COMMUNICATIONS SETUP PRESS <STEP> TO CONTINUE c. -
Page 18: Sending Console Commands
Operation Viewing PMC Reports Via RS-232 Connection 6. After entering your port settings, the program’s main window appears (Figure 12). Figure 12. HyperTerminal main window SENDING CONSOLE COMMANDS Table 3 shows three important PMC console commands: IV8200, IV8000, and IV8100. The <SOH> shown in the table means that you must press and hold the Ctrl key while you press the A key. - Page 19 Operation Viewing PMC Reports Via RS-232 Connection Table 3. Serial Commands for PMC Diagnostic Reports Report Type Serial Command (PC to Console)* Vapor Processor Status Report <SOH>IV8200 (See example Figure 13) Vapor Processor Runtime Diagnostic Report <SOH>IV8000 (See example Figure 14) Percent Hydrocarbon Diagnostic Report (See <SOH>IV8100 example Figure 15)
-
Page 20: Figure 13. Vapor Processor Status Report Details - Serial To Pc Format
Operation Viewing PMC Reports Via RS-232 Connection < S O H > I V 8 2 0 0 J U N 1 , 2 0 0 2 8 : 0 7 A M ( S I T E N A M E ) ( S I T E S T R E E T ) ( C I T Y , S T A T E ) ( P H O N E N U M B E R ) -
Page 21: Figure 14. Vapor Processor Runtime Diagnostic Report - Serial To Pc Format
Operation Viewing PMC Reports Via RS-232 Connection I V 8 0 0 0 A U G 3 0 , 2 0 0 7 1 1 : 5 2 A M ( S I T E N A M E ) ( S I T E S T R E E T ) ( C I T Y , S T A T E ) ( P H O N E N U M B E R ) -
Page 22: Figure 15. Percent Hydrocarbon Diagnostic Report - Serial To Pc Format
Operation Viewing PMC Reports Via RS-232 Connection I V 8 1 0 0 A U G 3 0 , 2 0 0 7 1 1 : 5 3 A M H Y D R O C A R B O N S E N S O R D I A G N O S T I C D A T E / T I M E R E A D I N G % 8 - 2 5 - 0 7 7 : 5 8 A M 1 . -
Page 23: Diagnostics
Diagnostics Automatic Control and Runtime Fault Alarm Under automatic control, vapor pressure readings are compared to user programmable thresholds to determine the appropriate Pressure Management Device (PMD) state. When the PMD is off and the OVERPRESSURE LIMIT is exceeded, an internal relay is enabled and remains so until the pressure drops below the TURN OFF VAPOR PROCESSOR threshold. - Page 24 For technical support, sales or other assistance, please visit: www.veeder.com Section 16 Pressure Management Control 16-20...
