Applied Biosystems QuantStudio 3 Site Preparation Manual page 6

Site requirements
Instrument and
computer
connections
6
1
2
3
4
5
6 6
7
Figure 1 Instrument back panel
USB ports
1
WiFi USB port—Connect USB wireless
2
adapter for wireless network access
(ordered separately)
Ethernet Port—RJ45 port for
3
100/1,000 Mbps Ethernet communication
with the instrument
3
1
Figure 2 Instrument‑to‑computer connections (minitower configuration)
1 Detachable power supply cord compatible with local power supply receptacle.
Connection between the computer and the instrument.
2
Connection between the computer and the monitor, keyboard, and mouse.
3
Connection between the computer and the
4
QuantStudio 3 and 5 Real-Time PCR Systems Site Preparation Guide | MAN0010405 C.0
™
RS232 Port—For service use only
4
Fuse Cover
5
Power Switch
6
Power Port—100 to 240 VAC
7
2
1
4
(optional) handheld barcode scanner.
