Site requirements

Dimensions and
weights
Package
Instrument (on pallet)
[1]
Computer (laptop)
[1]
Computer (minitower)
[1]
Monitor (with stand)
[1]
A computer (laptop or minitower), monitor, and keyboard are optional equipment.
Component
Instrument
[1]
Computer (laptop)
[1]
Computer (minitower)
[1]
Monitor (with stand)
[1]
Keyboard
[1]
A computer (laptop or minitower), monitor, and keyboard are optional equipment.
Instrument
clearances
QuantStudio 3 and 5 Real-Time PCR Systems Site Preparation Guide | MAN0010405 C.0
™
Note: All measurements are rounded to the nearest whole- or half-unit.
Components (packaged)
WARNING! PHYSICAL INJURY HAZARD. The packages are heavy. Do not
attempt to lift or move the packages without professional assistance. Any
incorrect lifting or moving of the packages can cause serious injury.
Ensure the building clearances allow for the passage of the instrument packaging.
Height
63 cm (25 in.)
22 cm (9 in.)
36 cm (14 in.)
18 cm (7 in.)
Components (unpacked)
Ensure that the installation site bench space can accommodate the dimensions and
support the weights of the purchased configuration.
Height
40 cm (16 in.)
4 cm (1.5 in.)
36 cm (14 in.)
37 cm (15 in.)
3 cm (1.5 in.)
During instrument installation and maintenance, it is necessary to access the back of
the instrument. If the back of the instrument faces a wall, ensure that there is sufficient
clearance on the bench to rotate the instrument for access.
IMPORTANT! For safety, the power outlet for the instrument must be accessible.
Component
Instrument 30 cm (12 in.)
[1]
Computer
[1]
Co-locating the computer with the instrument is optional.
Length (depth)
69 cm (27 in.)
42 cm (16.5 in.)
47 cm (18.5 in.)
46 cm (18 in.)
Length (depth)
50 cm (20 in.)
25 cm (10 in.)
42 cm (16.5 in.)
18 cm (7 in.)
14 cm (5.5 in.)
Top Front
30 cm (12 in.)
— 15 cm (6 in.)
Site requirements
Width
42 cm (16.5 in.) 35 kg (77 lb)
59 cm (23 in.) 7 kg (15 lbs)
54 cm (21 in.) 14.5 kg (32 lb)
41 cm (16 in.) 7 kg (15 lbs)
Width
27 cm (10.5 in.) 26 kg (57 lbs)
38 cm (15 in.) 2.5 kg (5 lbs)
17.5 cm (7 in.) 9.5 kg (21 lbs)
41 cm (16 in.) 5 kg (11 lbs)
45 cm (18 in.) 1 kg (2.5 lbs)
Sides
15 cm (6 in.) 15 cm (6 in.)
— 15 cm (6 in.)
Weight
Weight
Back
